23
DISASSEMBLY AND REASSEMBLY
3-7) Moving tray
Moving tray
Part Name How To Do Descriptive Picture
1. When pulling out the Moving
tray, if it is not slid out well, lift it
up slightly and pull out again.
3-8) Vegetable & Fruit Drawers Shelf
Vegetable & Fruit
Drawers Shelf
Part Name How To Do Descriptive Picture
1. Remove the vegetable & fruit
drawer by pulling the roller part
and lifting it up.
2. Remove the vegetable & fruit
drawer shelf by pulling it out.
(Refer to the picture)
3. Remove the vegetable & fruit
drawer partition by pulling it out.
(Refer to the picture)
NW-미주향-AC 2010.6.8 3:46 PM 페 이 지 2 3 i n
To Next Page
