22
DISASSEMBLY AND REASSEMBLY
3-5) Refrigerator Light
Refrigerator Light
Part Name How To Do Descriptive Picture
1. Remove the lamp cover by
pulling it down as pushing the
rear of lamp cover.
2. Separate the LED panel.
3. Remove the LED panel by lifting
the left part of LED panel while
pushing it to right. (Refer to
pictrue)
3-6) Glass shelves
Glass shelves
Part Name How To Do Descriptive Picture
1. When pulling out the shelf, if it is
not slid out well, lift it up slightly
and pull out again.
