Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 4-1
AH26-00130A TRANS POWER -,RCD-M70,-,-,115/230V,-,-,-,5
AH39-10001K POWER-CORD CP2,KLCE-2F,2M,KKS-15,VDE
AH59-00043G REMOCON-ASSY RCDM70,-,-,-,15KEY,-,-,-,-,-,-
AH68-00674E MANUAL-USERS RUSSIAN
AH92-00755A ASSY PCB RCDM70,MAIN PCB
ED1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
FD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
FD2 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
FD3 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
ID1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
ID2 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD2 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD3 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD4 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD88 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD89 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
KD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
KD2 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
KD3 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
KD4 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
KD5 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
KD6 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
RD6 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
RD88 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD1-5 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD50-55 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD60-61 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD7 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD8 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
CD2 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
CD3 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
UND1 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
0403-000362 DIODE-ZENER UZ6.2BSC,6.2V,6.16-6.4V,500
BZD1 0403-000379 DIODE-ZENER UZP12B,12V,11.4-12.6V,1W,DO
HZD1 0403-000393 DIODE-ZENER UZP5.1B,5.1V,4.8-5.4V,1W,DO
RZD1 0403-000398 DIODE-ZENER UZP8.2B,8.2V,7.7-8.7V,1W,DO
OKV1 0405-001061 DIODE-VARACTOR SVC344,30V,100NA,TP
JQ1 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
JQ2 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
JQ5 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
JQ51 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
JQ52 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
QQ3 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
RIC1 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
RQ2 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
ZQ3 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
IQ2 0501-000294 TR-SMALL SIGNAL KSA708-YTA,PNP,-80V,-60V,
CQ1 0501-000303 TR-SMALL SIGNAL KSA733YTA,PNP,-60V,-50V,-150mA
JQ4 0501-000303 TR-SMALL SIGNAL KSA733YTA,PNP,-60V,-50V,-150mA
SQ4 0501-000303 TR-SMALL SIGNAL KSA733YTA,PNP,-60V,-50V,-150mA
UQ1 0501-000303 TR-SMALL SIGNAL KSA733YTA,PNP,-60V,-50V,-150mA
UQ4 0501-000303 TR-SMALL SIGNAL KSA733YTA,PNP,-60V,-50V,-150mA
IQ1 0501-000392 TR-SMALL SIGNAL KSC838-OTA,35V,30V,30mA,250
KQ31 0501-000394 TR-SMALL SIGNAL KSC900-LTA,30V,25V,50mA,250
KQ1 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
KQ51 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
QQ1 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
QQ51 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
UQ12 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
RQ1 0501-000610 TR-SMALL SIGNAL KSA928A,PNP,-30V,-30V,-2A,1W
ZQ2 0501-000610 TR-SMALL SIGNAL KSA928A,PNP,-30V,-30V,-2A,1W
KQ2 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ2 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
CQ5 0504-000121 TR-DIGITAL KSR1007TA/108M,300MW,22K-47K
UQ3 0504-000121 TR-DIGITAL KSR1007TA/108M,300MW,22K-47K
CQ2 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
CQ3 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
JQ56 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
JQ6 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
SQ2 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
ZQ5 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
ZQ55 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
CQ4 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
IQ3 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
JQ3 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
QQ2 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
UQ5 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
BLED1 0601-001385 LED LTL-87HKESS-UA,PURE GRN
BLED2 0601-001385 LED LTL-87HKESS-UA,PURE GRN
BLED3 0601-001385 LED LTL-87HKESS-UA,PURE GRN
BLED4 0601-001385 LED LTL-87HKESS-UA,PURE GRN
BLED5 0601-001385 LED LTL-87HKESS-UA,PURE GRN
BLED6 0601-001385 LED LTL-87HKESS-UA,PURE GRN
AR1 2001-000003 R-CARBON 330ohm,5%,1/8W,AA,TP,1.8x3.2mm
AR51 2001-000003 R-CARBON 330ohm,5%,1/8W,AA,TP,1.8x3.2mm
IR1 2001-000003 R-CARBON 330ohm,5%,1/8W,AA,TP,1.8x3.2mm
IR4 2001-000003 R-CARBON 330ohm,5%,1/8W,AA,TP,1.8x3.2mm
IR3 2001-000005 R-CARBON 390ohm,5%,1/8W,AA,TP,1.8x3.2mm
JR6 2001-000008 R-CARBON 15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
BR5 2001-000034 R-CARBON 220ohm,5%,1/4W,AA,TP,2.4x6.4mm
2001-000038 R-CARBON 390ohm,5%,1/4W,AA,TP,2.4x6.4mm
KR2 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
KR52 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR2 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR12 2001-000273 R-CARBON 100Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR62 2001-000273 R-CARBON 100Kohm,5%,1/8W,AA,TP,1.8x3.2m
UR4 2001-000273 R-CARBON 100Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR16 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
QR4 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
SR12 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
UNR1 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
UNR11 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
UNR2 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
UNR3 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
UNR4 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
UNR5 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
UNR6 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
CR5 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR5 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR55 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR3 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR14 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR15 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR16 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
IR23 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
IR24 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR14 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR16 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR9 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
KR66 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
OR11 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
QR57 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
QR58 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
QR7 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
QR8 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR9 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR10 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR11 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR59 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR9 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
UR17 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
UR18 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
UR32 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
ZR5 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
ZR55 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
UR159 2001-000295 R-CARBON 10MOHM,5%,1/8W,AA,TP,1.8*3.2
IR14 2001-000302 R-CARBON 10ohm,5%,1/8W,AA,TP,1.8x3.2mm
RR5 2001-000302 R-CARBON 10ohm,5%,1/8W,AA,TP,1.8x3.2mm
KR57 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
KR7 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR10 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
BR6 2001-000362 R-CARBON 150ohm,5%,1/8W,AA,TP,1.8x3.2mm
BR7 2001-000362 R-CARBON 150ohm,5%,1/8W,AA,TP,1.8x3.2mm
BR8 2001-000362 R-CARBON 150ohm,5%,1/8W,AA,TP,1.8x3.2mm
CR2 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR4 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
IR29 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR1 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR2 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR5 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR51 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR52 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR55 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR7 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR8 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
ZR4 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
ZR56 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
ZR6 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR10 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR11 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR12 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR13 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR17 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR2 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR3 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR5 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR10 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR11 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR40 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR60 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR61 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
KR58 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
KR8 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
QR56 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
QR6 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
Location no. Code no. Description & Specifiation Remarks
Location no. Code no. Description & Specifiation Remarks
4. Electrical Parts List
*S.N.A. : Service Not Available
