Connecting the LAN Cable

―

Connecting parts may differ in different products.

LAN

PC IN

LAN

USB

(0.5A)

USB

(1.0A)

HDMI 1

ANT IN

HDMI 2

(ARC)

HDMI 3

AV IN

AUDIO

OUT

RS232C IN

VIDEO

AUDIO

•

Use Cat7(*STP Type) cable for the connection.

*Shielded Twist Pair
