Samsung Electronics 3-1
3. Product Specifications and Comparison Chart
3-1 Product Specifications
Design and specifications are subject to change without notice.
Operation
Description
SYSTEM
Recording systems Video : 2 rotary heads, helical scanning FM sytem
Audio : FM system
Video signal NTSC color, EIA standard
Cassette format 8 mm
Tape speed SP mode (Standard Play) : approx. 14.3 mm/sec.
Recording/ Playback time SP mode (Standard Play) : 1 hour 30 minutes (P6-90)
Fast-forward/rewind time Approx. 4 min (P6-60)
Image device CCD (Charge Coupled Device)
Viewfinder SCA20 : Black and White electronic viewfinder
SCA23/SCA25 : Color electronic viewfinder
Lens SCA23/SCA25 : Combined 16x power zoom and 64x digital zoom
SCA20 : Combined 16x power zoom and 32x digital zoom
f=3.9 ~ 62.4 mm, F1.4 Auto wide macro
Automatic focus system Inner
Color temperature Auto
Lighting 300 lux (28 footcandles)
Aperture correction Automatic with back light adjustment
INPUT/OUTPUT CONNECTORS
Video output Phono jack / 1Vp-p, 75 ohms, unbalanced, sync negative
Audio output Phono jack, 7.5dBs for an output impedance of less than 2.2 Kohms
GENERAL
Power requirement AC power adaptor (7.5V) ; battery pack (6.0V)
Power consumption(in Camera mode)
5.2W
Tripod attachment thread Attachment screw less than 9mm long
Microphone Electric condensor microphone, omni-directional, monaural typ
Temperature range Operation : 0°C to 40°C (32°F to 104°F); storage : -20°C to 60°C (-4°F to 140°F)
Dimensions/weight Appros. 97 X 107 X 196 mm (3.8 X 4.2 X 7.7 inches) /
approx. 700 g (1.54 lbs) Excluding battery pack and cassette
