Samsung SCA23 - Electrical Parts List

140 AD90-10833B ASSY-MAIN BOARD;SC-A25,NTSC
140 AD90-10829H ASSY-MAIN BOARD;SC-A23,NTSC
140 AD90-10823S ASSY-MAIN BOARD;SC-A20,NTSC
AUDIO BLOCK
C701 2404-000250 C-TA,CHIP;470nF,20%,25V,-,TP,3216,-
C702 2404-000250 C-TA,CHIP;470nF,20%,25V,-,TP,3216,-
C703 2402-001013 C-AL,SMD;47uF,20%,6.3V,GP,5.3x1.5x5.4,1
C704 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C705 2404-000367 C-TA,CHIP;4.7UF,20%,6.3V,-,TP,3216,-
C706 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
C707 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C708 2404-000367 C-TA,CHIP;4.7UF,20%,6.3V,-,TP,3216,-
C709 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C710 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C711 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C712 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C713 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C714 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,1608,1.6m
C715 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C716 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C717 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C718 2404-000367 C-TA,CHIP;4.7UF,20%,6.3V,-,TP,3216,-
C719 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C720 2404-000175 C-TA,CHIP;2.2uF,20%,6.3V,WT,3216,1.1mm,T
C721 2404-000259 C-TA,CHIP;47uF,20%,6.3V,-,TP,6032,-
C722 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C723 2404-000250 C-TA,CHIP;470nF,20%,25V,-,TP,3216,-
C726 2404-000259 C-TA,CHIP;47uF,20%,6.3V,-,TP,6032,-
C727 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C851 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C852 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
C853 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C854 2404-000367 C-TA,CHIP;4.7UF,20%,6.3V,-,TP,3216,-
C855 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C856 2203-001662 C-CERAMIC,CHIP;5.6NF,10%,50V,CH,TP,1608,
CN851 3711-002127 CONNECTOR-HEADER;BOX,8P,1R,1.25mm,SMD-A,
IC701 1204-001307 IC-AUDIO PROCESSOR;LA7457W,QFP,64P,10MIL
L701 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
Q701 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q702 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q703 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q851 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q852 0506-000150 TR-ARRAY;UMX2N,NPN,2,50V,40V,100MA,300M
R701 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R702 2007-000691 R-CHIP;3.3Mohm,5%,1/16W,DA,TP,1608
R703 2007-000819 R-CHIP;390Kohm,5%,1/16W,DA,TP,1608
R704 2007-000819 R-CHIP;390Kohm,5%,1/16W,DA,TP,1608
R705 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R706 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R707 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R708 2007-000133 R-CHIP;330Kohm,5%,1/16W,DA,TP,1608
R709 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R710 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R711 2007-000691 R-CHIP;3.3Mohm,5%,1/16W,DA,TP,1608
R712 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R713 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R714 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R717 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
R720 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R721 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
R722 2007-000462 R-CHIP;18ohm,5%,1/10W,DA,TP,2012
R723 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
R725 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R726 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R728 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608
R801 2007-000072 R-CHIP;47ohm,5%,1/16W,DA,TP,1608
R850 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R851 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R852 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
R853 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R854 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R855 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
R856 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
R857 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R858 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R859 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R860 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP 200
R861 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R862 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R863 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
R864 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R865 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R866 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
CAMERA MAIN BLOCK
CNP01 3710-001110 CONNECTOR-SOCKET;18P,2R,0.8MM,SMD-S,AU
CNP02 3708-001262 CONNECTOR-FPC/FC/PIC;22P,0.5mm,SMD-A,SN
CNP03 3711-002049 CONNECTOR-HEADER;BOX,6P,1R,1.25mm,SMD-A,
CP01 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
CP02 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CP05 2203-001573 C-CERAMIC,CHIP;12pF,5%,50V,CH,1608,1.6mm
CP11 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP12 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP13 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP14 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP18 2404-000159 C-TA,CHIP;1uF,20%,35V,-,TP,3528,-
CP20 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CP21 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP22 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP23 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
CP24 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP25 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP26 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CP27 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CP28 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
CP29 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
CP30 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
CP31 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
CP34 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CP35 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP37 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
CP38 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP39 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP40 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP41 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP42 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP47 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP48 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
CP50 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
CP52 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP53 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP54 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,
CP55 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
CP56 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP57 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP58 2404-000190 C-TA,CHIP;22uF,20%,16V,-,5832,-,TP
CP60 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP61 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CP62 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CP63 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CP64 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
CP65 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
CP66 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
CP67 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
Samsung Electronics
7-1
Loc.No Part No Desc & Spec Remark Loc.No Part No Desc & Spec Remark
7. Electrical Parts List
