Disassembly and Reassembly
Samsung Electronics 4-13
ΠREMOVE 1 SCREW
ˇ REMOVE THE BRACKET-LENS.
´ REMOVE 1 SCREW.
¨ REMOVE 2 SCREWS.
ˆ REMOVE THE ASS'Y PCB-CCD
4-1-13 Ass’y Camera Removal (2)
Fig. 4-13 Ass’y Camera Removal (2)
