Alignment and adjustment
5-12 Samsung Electronics
SCA20 SCA23 SCA25
MODE OSD DATA1 DATA2 DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
DF 00 00 00 00 00 00 NOT USED
E0 AA AA AA AA AA AA BK NOISE TH/GAIN OF EIS
E1 5F 5F 5F 5F 5F 5F H APPERTURE GAIN OF EIS
E2 FF FF FF FF FF FF #0C OF EIS ON
E3 O7 O7 O7 O7 O7 O7 #OD OF EIS ON
E4 A8 A8 A8 A8 A8 A8 #OE OF EIS ON
E5 10 10 10 10 10 10 #OF OF EIS ON
E6 OO OO OO OO OO OO #18 OF EIS ON
E7 O1 O1 O1 O1 O1 O1 EIS DEMO
E8 69 69 69 69 69 69 V GAIN-1(A/D GAIN)
E9 O8 O8 O8 O8 O8 O8 V GAIN-2(CCD GAIN)
EA EB EB EB EB EB EB V GAIN-3(CENTERING GAIN)
EB O8 O8 O8 O8 O8 O8 V STOP NOISE THRESHOULD
EC 8C 8C 8C 8C 8C 8C H GAIN-1(A/D GAIN)
ED O8 O8 O8 O8 O8 O8 H GAIN-2(CCD GAIN)
EE EB EB EB EB EB EB H GAIN-3(CENTERING GAIN)
EF OA OA OA OA OA OA H STOP NOISE THRESHOULD
F0 OO OO OO OO OO OO D-ZOOM STEP
F1 O1 O1 O1 O1 O1 O1 NOT USED
F2 80 80 80 80 80 80 R TARGET OF W/B ADJUST
F3 80 80 80 80 80 80 B TARGET OF W/B ADJUST
Note : On table you see the ÒXX XXÓ for DATA 1/DATA 2
ÒXX XXÓ means arbitrary value.
<Example of the TV screen>
CD HALLA XX XX
Data in
memory
Data to be
adjusted
