Samsung Electronics 5-29
Alignment and Adjustment
NO. Address Adjustment Test point Adjustment point Spec.
1 8 PLL PLL EVR 1.8±0.1V DC
2 2 BRIGHTNESS G-OUT EVR 8.0Vp-p
3 4 R-SUB BRIGHTNESS R-OUT EVR 8.0Vp-p
4 5 R-SUB BRIGHTNESS B-OUT EVR 8.0Vp-p
5 1 COLOR B-OUT EVR -
6 0 TINT B-OUT EVR -
Test point
ADJ. point
1. PLL
3. R-SUB BRIGHTNESS
2. BRIGHTNESS
PLL
R-OUT
B-OUT
G-OUT
CNE02
ICE02
CNE01
4. B-SUB BRIGHTNESS
5. COLOR
6. HUE
