Samsung Electronics 7-1
7. Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RE19 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE20 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE21 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE22 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE23 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 PAL/NTSC
RE24 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012 PAL/NTSC
RE25 2007-000689 R-CHIP;3.3MOHM,5%,1/10W,DA,TP,2012 PAL/NTSC
RE26 2007-000689 R-CHIP;3.3MOHM,5%,1/10W,DA,TP,2012 PAL/NTSC
RE27 2007-000462 R-CHIP;18OHM,5%,1/10W,DA,TP,2012 PAL/NTSC
VRE01 2104-001024 VR-SMD;68KOHM,25%,0.15W,TOP PAL/NTSC
VRE02 2104-001013 VR-SMD;220ohm,25%,0.15W,TOP PAL/NTSC
VRE03 2104-000178 VR-SMD;1MOHM,30%,1/20W,TOP PAL/NTSC
ASS'Y-CVF BOARD
CE01 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP PAL/NTSC
CE03 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, PAL/NTSC
CE04 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, PAL/NTSC
CE05 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, PAL/NTSC
CE09 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP, PAL/NTSC
CE10 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP, PAL/NTSC
CE11 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP, PAL/NTSC
CE12 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE13 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE14 2404-000390 C-TA,CHIP;100nF,20%,50V,GP,TP,3216,- PAL/NTSC
CE15 2404-000390 C-TA,CHIP;100nF,20%,50V,GP,TP,3216,- PAL/NTSC
CE16 2203-001140 C-CERAMIC,CHIP;68nF,10%,16V,X7R,TP,1608, PAL/NTSC
CE17 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE18 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,- PAL/NTSC
CE20 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE21 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,- PAL/NTSC
CE22 2404-000335 C-TA,CHIP;3.3uF,20%,16V,-,TP,3216,- PAL/NTSC
CE23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, PAL/NTSC
CE25 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608, PAL/NTSC
CE26 2404-000251 C-TA,CHIP;470nF,20%,35V,-,TP,3216,- PAL/NTSC
CE27 2404-000335 C-TA,CHIP;3.3uF,20%,16V,-,TP,3216,- PAL/NTSC
CE28 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608 PAL/NTSC
CE29 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1 PAL/NTSC
CE30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, PAL/NTSC
CE31 2203-001683 C-CERAMIC,CHIP;68pF,5%,50V,CH,TP,1608,1. PAL/NTSC
CE32 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP PAL/NTSC
CE33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE34 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE35 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE36 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608 PAL/NTSC
CE37 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE38 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE39 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE40 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,- PAL/NTSC
CE42 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE43 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP PAL/NTSC
CE44 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,- PAL/NTSC
ASS'Y-EVF BOARD
CE01 2203-000315 C-CERAMIC,CHIP;120pF,5%,50V,NPO,TP,1608, PAL/NTSC
CE02 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE03 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP PAL/NTSC
CE04 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 PAL/NTSC
CE05 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,- PAL/NTSC
CE06 2309-001001 C-FILM,CHIP;100nF,5%,16V,3.2x2.5x2.0mm,- PAL/NTSC
CE07 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE08 2404-000128 C-TA,CHIP;10uF,20%,16V,-,TP,6032,- PAL/NTSC
CE09 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608, PAL/NTSC
CE10 2402-000144 C-AL,SMD;3.3uF,20%,50V,GP,TP,4.3x4.3x5. PAL/NTSC
CE11 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 PAL/NTSC
CE12 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP PAL/NTSC
CE13 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP PAL/NTSC
CE14 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP PAL/NTSC
CE15 2309-000143 C-FILM,CHIP;3.9nF,5%,100V,-,-,TP PAL/NTSC
CE16 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE17 2402-000144 C-AL,SMD;3.3uF,20%,50V,GP,TP,4.3x4.3x5. PAL/NTSC
CE18 2201-000911 C-CERAMIC,DISC;1.2nF,10%,1KV,Y5P,BK,10x5 PAL/NTSC
CNE01 3711-000862 CONNECTOR-HEADER;BOX,3P,1R,1.25mm,SMD-A, PAL/NTSC
CNE02 3711-002173 CONNECTOR-HEADER;BOX,4P,1R,1.5,STRAIGHT, PAL/NTSC
CNE03 AC03-12001B SOCKET-CRT;SOCKET FINDER,PI10 40MM,-,-,- PAL/NTSC
DE01 0407-000151 DIODE-ARRAY;MA153,40V,100mA,C2-3,SOT-23, PAL/NTSC
DE02 0401-000138 DIODE-SWITCHING;KDS193,80V,100mA,150mW,4 PAL/NTSC
DE03 0401-000166 DIODE-SWITCHING;MA158-TX,200V,100mA,-,-, PAL/NTSC
FTB01 AC26-32001B TRANS-FLYBACK;ECX-C2806D,0.6INCH,4.8V PAL/NTSC
ICE01 AC14-12006W IC-LINEAR;KA7007,SOP,- PAL/NTSC
LE01 2703-001756 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm PAL/NTSC
LE02 AC27-32001B COIL-LINEARITY;230UH-15%,PI0.12,T,-,- PAL/NTSC
QE01 0501-000424 TR-SMALL SIGNAL;KTA1504-Y,PNP,150mW,SOT- PAL/NTSC
QE02 0501-000238 TR-SMALL SIGNAL;2SD968A,NPN,1W,SC-62,-,1 PAL/NTSC
QE03 0501-000424 TR-SMALL SIGNAL;KTA1504-Y,PNP,150mW,SOT- PAL/NTSC
RE01 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE02 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE03 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE04 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE05 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE06 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE07 2007-000637 R-CHIP;270Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE08 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE09 2007-000695 R-CHIP;3.3ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE10 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE11 1404-001138 THERMISTOR-NTC;470ohm,10%,3100K,140mW/C, PAL/NTSC
RE12 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012 PAL/NTSC
RE13 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE14 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE15 2007-000965 R-CHIP;5.1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE16 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE17 2007-001056 R-CHIP;6.2Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE18 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
To Next Page
