Samsung Electronics7-2
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CE45 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CE46 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP PAL/NTSC
CE50 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP PAL/NTSC
CE51 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, PAL/NTSC
CNE01 3711-000386 CONNECTOR-HEADER;3WALL,10P,1R,1.25mm,SMD PAL/NTSC
CNE01 3711-002172 CONNECTOR-HEADER;BOX,3P,1R,1.5,STRAIGHT, NTSC
CNE02 3708-000514 CONNECTOR-FPC/FC/PIC;16P,0.5MM,SMD-S,SN PAL/NTSC
CNE03 3711-002613 CONNECTOR-HEADER;3WALL,3P,1R,1.25MM,SMD- PAL/NTSC
DE01 0405-000123 DIODE-VARACTOR;1T369,34V,10nA,DSM,TP PAL/NTSC
DE02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323 PAL/NTSC
DE03 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323 PAL/NTSC
DE04 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323 PAL/NTSC
DE05 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323 PAL/NTSC
FLE01 4713-001071 LAMP;5V,-,0.4W,WHT,-,-,- NTSC
ICE01 1003-001168 IC-LCD DRIVER;CXA2503AR,QFP,64P,400MIL,T PAL/NTSC
ICE02 1103-001133 IC-EEPROM;24C020,256x8BIT,SOP,8P,150MIL, PAL/NTSC
ICE03 AD14-10001C IC-AMP;NJM2904V,SSOP,OP-AMP PAL/NTSC
ICE04 0801-000301 IC-CMOS LOGIC;7W04,INVERTER,SOP,8P,150MI PAL/NTSC
LE01 AC40-22002F CONVERTER-COIL;-,- NTSC
LE03 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm PAL/NTSC
LE04 2703-001760 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm PAL/NTSC
LE05 2703-001760 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm PAL/NTSC
LE06 2703-001761 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm PAL/NTSC
LE07 2703-000366 INDUCTOR-SMD;22uH,5%,2.5x2x1.8mm PAL/NTSC
QE01 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP PAL/NTSC
QE02 0506-000138 TR-ARRAY;IMZ1,NPN/PNP,1,50V,40V,100mA,3 PAL/NTSC
QE03 0504-000211 TR-DIGITAL;DTC143TU,NPN,200MW,4.7K,SC-70 PAL/NTSC
QE04 0504-000211 TR-DIGITAL;DTC143TU,NPN,200MW,4.7K,SC-70 PAL/NTSC
QE05 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT- PAL/NTSC
QE08 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP PAL/NTSC
QEB01 0505-001231 FET-SILICON;2SK1474,N,100V,4A,0.4ohm,20W NTSC
RE01 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE02 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE03 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE04 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE07 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE08 2007-000637 R-CHIP;270Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE09 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE10 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE11 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE12 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE13 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE14 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE16 2007-001157 R-CHIP;750ohm,5%,1/16W,DA,TP,160 PAL/NTSC
RE18 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE19 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE20 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE21 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE22 2007-000614 R-CHIP;24Kohm,1%,1/16W,DA,TP,1608 PAL/NTSC
RE23 2007-000239 R-CHIP;1.5Kohm,1%,1/16W,DA,TP,1608 PAL/NTSC
RE24 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE25 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608 PAL/NTSC
RE26 2007-000614 R-CHIP;24Kohm,1%,1/16W,DA,TP,1608 PAL/NTSC
RE27 2007-000683 R-CHIP;3.3Kohm,1%,1/16W,DA,TP,1608 PAL/NTSC
RE28 2007-000067 R-CHIP;15Kohm,1%,1/16W,DA,TP,1608 PAL/NTSC
RE29 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE30 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE31 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE32 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE34 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE40 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE44 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE45 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE47 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE50 2203-000426 C-CERAMIC,CHIP;18pF,5%,50V,NPO,1608,-,TP PAL/NTSC
RE51 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE57 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE58 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE61 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE62 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 PAL/NTSC
RE63 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 PAL/NTSC
XE01 2801-003126 CRYSTAL-SMD;4.433619MHz,30ppm,28-ABN,16p PAL/NTSC
XE01 2801-003127 CRYSTAL-SMD;3.579545MHz,30ppm,28-ABN,16p NTSC
ASS'Y-CCD BOARD
CC01 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,1608
CC02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC03 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC04 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC05 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CC06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CNC01 3711-004241 CONNECTOR-HEADER;BOX,18P,2R,1MM,SMD-A,SN
DC02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
QC01 0505-000180 FET-SILICON;2SK1070PIETR,-,150MW,SOT
RC01 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RC02 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RC03 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RC05 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RC07 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
ASS'Y-MAIN BOARD
C001 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C002 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, NORMAL
C002 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 HI8
C003 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C004 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C005 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C006 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608 NORMAL
C006 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP HI8
C007 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C008 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, HI8
C008 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP NORMAL
