Samsung Electronics 7-3
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
C009 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C010 2203-000783 C-CERAMIC,CHIP;330pF,5%,50V,NPO,TP,1608, Hi8
C010 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,- NORMAL
C011 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, NORMAL
C011 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP Hi8
C012 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C013 2203-001640 C-CERAMIC,CHIP;390pF,10%,50V,X7R,TP,1608 Hi8
C013 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,- NORMAL
C014 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, NORMAL
C014 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,- Hi8
C015 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, Hi8
C015 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, NORMAL
C016 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, Hi8
C016 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608, NORMAL
C017 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, Hi8
C017 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608, NORMAL
C018 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, NORMAL
C018 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,- Hi8
C019 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608, Hi8
C019 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,- NORMAL
C020 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, NORMAL
C020 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608, Hi8
C021 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C022 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, NORMAL
C022 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,- Hi8
C023 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C024 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C025 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C026 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C027 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C028 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C029 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C030 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C031 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C032 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C033 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C034 2203-001113 C-CERAMIC,CHIP;62pF,5%,50V,NPO,TP,1608,- NORMAL
C034 2203-001417 C-CERAMIC,CHIP;36pF,5%,50V,NPO,TP,1608,1 Hi8
C035 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C037 2203-001408 C-CERAMIC,CHIP;270pF,5%,50V,COG,TP,1608,
C038 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C039 2203-000426 C-CERAMIC,CHIP;18pF,5%,50V,NPO,1608,-,TP
C044 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
C045 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
C046 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
C047 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
C048 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,-
C049 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
C050 2203-000815 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,-
C052 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C053 2203-001686 C-CERAMIC,CHIP;75pF,5%,50V,CH,TP,1608,1.
C054 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C055 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C056 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C060 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,- NORMAL/PAL
C060 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
NORMAL/NTSC
C061 2203-001408 C-CERAMIC,CHIP;270pF,5%,50V,COG,TP,1608,
C1 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C10 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, Hi8
C10 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP, NORMAL
C101 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C102 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C103 2203-000426 C-CERAMIC,CHIP;18pF,5%,50V,NPO,1608,-,TP
C104 2203-000426 C-CERAMIC,CHIP;18pF,5%,50V,NPO,1608,-,TP
C105 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C106 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C107 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C108 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C109 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C11 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C110 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C111 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C112 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C113 2203-000315 C-CERAMIC,CHIP;120pF,5%,50V,NPO,TP,1608,
C114 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C115 2203-000851 C-CERAMIC,CHIP;39pF,5%,50V,NPO,TP,1608,-
C116 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C117 2203-000426 C-CERAMIC,CHIP;18pF,5%,50V,NPO,1608,-,TP
C118 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C119 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C12 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C120 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C121 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C122 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C123 2203-001195 C-CERAMIC,CHIP;7pF,0.25pF,50V,NPO,TP,160
C124 2203-002605 C-CERAMIC,CHIP;8pF,0.25pF,50V,CH,TP,1608
C125 2203-000426 C-CERAMIC,CHIP;18pF,5%,50V,NPO,1608,-,TP
C126 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C127 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C128 2203-001640 C-CERAMIC,CHIP;390pF,10%,50V,X7R,TP,1608
C129 2203-001083 C-CERAMIC,CHIP;5pF,0.1pF,50V,NPO,TP,1608
C13 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C130 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C131 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C132 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C133 2203-000815 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,-
C134 2203-000315 C-CERAMIC,CHIP;120pF,5%,50V,NPO,TP,1608,
C135 2203-000998 C-CERAMIC,CHIP;47pF,5%,50V,NPO,TP,1608,-
C136 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C137 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
