4-2 Circuit Boards Location
ASS'Y MAIN BOARD
ASSY CCD BOARD
ASS'Y FUNCTION BOARD
ASS'Y EVF BOARD
ASS'Y REAR BOARD
ASS'Y CVF BOARD
ASS'Y EIS BOARD (EIS MODEL)
ASS'Y FRONT BOARD (NO EIS MODEL)
Fig. 4-10 Circuit Boards Location
