Samsung Electronics 4-11
Disassemblr and Reassembly
4-3 Connector Diagrams
Fig. 4-11 Connector Diagrams
NO. NO.CONNECTOR CONNECTORDIRECTION
CN51 CN501
DECK MAIN PCB
CN52
CN601 CN771
CN603
CN604
CNP01 CNC01
CN894
CN894
CNP03
CNP02
CNP801
CN801
CN802
CN891
CN893
CN893
CN895
CN472
CN890
DECK MAIN PCB
MAIN PCB
MAIN PCB
REAR PCB
FUNCTION PCB
MAIN PCB CVF
MAIN PCB CCD PCB
MAIN PCB
MAIN PCB
MAIN PCB
MAIN PCB
MAIN PCB
LENS FPC
LENS FPC
FRONT PCB
FRONT PCB
FRONT PCB
FRONT PCB
FUNCTION PCB
FRONT FFC
FRONT FFC
FRONT PCB
MIC ASS’Y
MIC ASS’Y
MIC ASS’Y
LIGHT ASS’Y
EVF
Caution of assembling (CN604 of the CVF models) :
Insert the cable to the left most side of CN604
(Pin no.1 side)
