Samsung Electronics 5-1
5. Alignment and Adjustment
5-1. Mechanism Alignment
• Refer to mechanical manual “DE-6 (AD68-30200A)”for the adjustment and checks of mechanism section.
• The location of test point (See Fig.1)
Test Point:
PB RF - Pin 11 of CN605
Head Switching Trigger - Pin 9 of CN605
14
12
10
8
6
4
2
13
11
9
7
5
3
1
PB RF
Head Switching - Trigger
CN605
Fig. 1 Test point
Fig. 2 Test location of test point
