ADDR OSD-DISPLAY CONTENT
0DF T.INI TABLE INITIAL
0CD HALL HALL AUTO ADJUST
0CE IRIS IRIS AUTO ADJUST
0CF AWB AWB AUTO ADJUST
0D0 LENS LENS AUTO ADJUST( WARNING! DON’T USE WITHOUT AN INFINITE COLLIMATOR)
0D6 ZVR.C ZOOM LEVER CENTER DATA CHECKING
0DB AGCM AGC AUTO ADJUST (NORMALLY NO USED)
0DE 3MLENS 3M LENS AUTO ADJUST AT SERVICE FIELD (DISTANCE: 3M +/- 1Cm)
NO-OSD-DISPLAY
ADDR MODEL/DATA CONTENT (EEPROM DATA PAGE 0)
PAL NTSC
HI8 NORMAL HI8 NORMAL BIT SEGMENTATION EXPLAIN
ADDR DATA D7 D6 D5 D4 D3 D2 D1 D0
001 50 50 50 50 OPTION AGC TARGET- 0'=FIX WDR='1' PASTEL COLOR KEY/RING CAN/SECREM EMBOSS COLOR
002 00 00 00 00 @IRIS CONTROL-LOW
003 08 08 08 08 @IRIS CONTROL-HIGH
004 F0 F0 F0 F0 * AWB-HSS MODE * AWB STOP HALL
005 80 80 80 80 @P.CLK PWM-HIGH
006 30 30 30 30 AGC TARGET DOWN VALUE AT 001H D6='1' OPTION
007 00 00 00 00 AGC MAX, DARK SLICE-B CONTROL
008 08 08 08 08 @UPD16835 INIT 4th
009 66 66 66 66 @UPD16835 INIT 6th
00A 66 66 66 66 @UPD16835 INIT 7th
00B 00 00 00 00 @UPD16835 standard data current set A(4th.7) : D0, current set B(7th.7) : D1
00C 03 03 03 03 @CDS F-REG(f1,f0) CAM : BIT0:f0,BIT1:f1
00D A0 A0 A0 A0 changed by AUTO HALL ADJ(0CD) "@CDS F-REG(f9,f2) CAM ;PGA GAIN -HIGH(0.00dB~ 30.0dB)"
00E 60 60 60 60 changed by AUTO HALL ADJ(0CD) "@CDS G-REG CAM ;DAC1(HALL REFERENCE CONTROL;0V~3.0V);"
00F 3A 3A 3A 3A "@CDS H-REG CAM ;DAC2(HALL GAIN CONTROL;0V~3.0V); "
010 87 87 87 87 "@CDS E-R(e1,e0),J-R(j0),M-R;D0:e0,D1:e1,D2:j0(CAM),D4:e0,D5:e1,D6:j0(VCR),D7:cds-rev='1'"
011 77 77 7B 80 "@CDS F-REG(f9,f2) VCR ;PGA GAIN -HIGH(0.00dB~ 10.0dB)"
012 00 00 00 00 @WDR REGISTER[7,0] *AEINSEL=D7,AELPFSEL=D6,X[5:0]
013 80 80 80 80 @WDR REGISTER[15,8] *AECLIP_TH[7:0]
014 00 00 00 00 @WDR REGISTER[23,16] *AEL_TH[7:0]
015 FF FF FF FF @WDR REGISTER[31,24] *AEH_TH[7:0]
016 8B 8B 76 76 @WDR REGISTER[39,32] *AEW2VE[7:0]
017 24 24 24 24 @WDR REGISTER[47,40] *AEW2VS[7:0]
018 ED ED F1 F1 @WDR REGISTER[55,48] *AEW2HE[7:0]
019 07 07 13 13 @WDR REGISTER[63,56] *AEW2HS[7:0]
01A 81 81 6E 6E @WDR REGISTER[71,64] *AEW1VE[7:0]
01B 26 26 20 20 @WDR REGISTER[79,72] *AEW1VS[7:0]
Samsung Electronics 5-5
Alignment and Adjustment
“CAMERA ADJUST MODE, EEPROM ADDRESS SEQUENCE & DATA OF PAGE 0”
