Samsung SCA30 - Page 82

Samsung Electronics7-4
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
C225 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
C225 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1
C225 2203-001656 C-CERAMIC,CHIP;470pF,5%,50V,CH,TP,1608,1
C226 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C227 2203-001640 C-CERAMIC,CHIP;390pF,10%,50V,X7R,TP,1608
C228 2203-001640 C-CERAMIC,CHIP;390pF,10%,50V,X7R,TP,1608
C229 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, NORMAL
C229 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608, Hi8
C23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C230 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C231 2203-000929 C-CERAMIC,CHIP;470pF,10%,50V,X7R,TP,1608 Hi8
C231 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1 NORMAL
C232 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20 NORMAL
C232 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP Hi8
C234 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C235 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C236 2203-000315 C-CERAMIC,CHIP;120pF,5%,50V,NPO,TP,1608, Hi8
C236 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608, NORMAL
C236 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1
C237 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C238 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C239 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C24 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C240 2203-001683 C-CERAMIC,CHIP;68pF,5%,50V,CH,TP,1608,1.
C241 2203-000315 C-CERAMIC,CHIP;120pF,5%,50V,NPO,TP,1608,
C243 2404-000250 C-TA,CHIP;470nF,20%,25V,-,TP,3216,-
C244 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C245 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C246 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C247 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C248 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C249 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C25 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C250 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C251 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C26 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C260 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C27 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C270 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C271 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C272 2203-001408 C-CERAMIC,CHIP;270pF,5%,50V,COG,TP,1608,
C273 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C28 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C281 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C282 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C283 2203-000405 C-CERAMIC,CHIP;180pF,5%,50V,NPO,TP,1608,
C29 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C292 2203-001113 C-CERAMIC,CHIP;62pF,5%,50V,NPO,TP,1608,-
C293 2203-000815 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,-
C3 2404-000218 C-TA,CHIP;330nF,20%,35V,-,TP,3216,-
C138 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C139 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C14 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C140 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C141 2203-000405 C-CERAMIC,CHIP;180pF,5%,50V,NPO,TP,1608,
C142 2203-001683 C-CERAMIC,CHIP;68pF,5%,50V,CH,TP,1608,1.
C143 2203-001113 C-CERAMIC,CHIP;62pF,5%,50V,NPO,TP,1608,-
C144 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C15 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C150 2203-001071 C-CERAMIC,CHIP;56pF,5%,50V,NPO,TP,1608,-
C151 2203-000998 C-CERAMIC,CHIP;47pF,5%,50V,NPO,TP,1608,-
C152 2203-000815 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,-
C153 2203-000041 C-CERAMIC,CHIP;10pF,0.25pF,50V,NPO,TP,16
C154 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C155 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C156 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C16 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C17 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C18 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C19 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C2 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
C20 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C201 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C202 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C203 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C204 2402-001008 C-AL,SMD;220uF,20%,4V,-,6.6x6.6x5.4mm,2
C205 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
C206 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C207 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C208 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C209 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C21 2404-000250 C-TA,CHIP;470nF,20%,25V,-,TP,3216,-
C210 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C211 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C212 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C213 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C214 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C215 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C216 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,- NORMAL/PAL
C216 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
NORMAL/NTSC
C218 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C219 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C22 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP,
C220 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
C221 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C222 2404-000218 C-TA,CHIP;330nF,20%,35V,-,TP,3216,-
C223 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
C224 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608, PAL
C224 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1 NTSC
C224 2203-001656 C-CERAMIC,CHIP;470pF,5%,50V,CH,TP,1608,1
