Samsung SCA30 - Page 83

Samsung Electronics 7-5
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
C514 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C515 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C516 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C517 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C518 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C519 2203-001630 C-CERAMIC,CHIP;330nF,+80-20%,16V,Y5V,TP,
C520 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C521 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C522 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
C523 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C524 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C525 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C526 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C527 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C528 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C529 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C530 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C531 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C532 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C534 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C535 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C536 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C537 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C538 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C539 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C541 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
C542 2203-001640 C-CERAMIC,CHIP;390pF,10%,50V,X7R,TP,1608
C543 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C544 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C545 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
C546 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C547 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C548 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C549 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C550 2404-000232 C-TA,CHIP;4.7uF,20%,10V,-,TP,3216,-
C551 2404-000232 C-TA,CHIP;4.7uF,20%,10V,-,TP,3216,-
C552 2203-000815 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,-
C553 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C601 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C602 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C603 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C604 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,-
C605 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,-
C606 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C607 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C608 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C609 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C610 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C611 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C612 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C30 2203-001652 C-CERAMIC,CHIP;470NF,+80-20%,16V,Y5V,TP, NORMAL
C30 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 Hi8
C31 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C311 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
C312 2203-000405 C-CERAMIC,CHIP;180pF,5%,50V,NPO,TP,1608,
C313 2203-000998 C-CERAMIC,CHIP;47pF,5%,50V,NPO,TP,1608,-
C314 2203-001697 C-CERAMIC,CHIP;.082NF,5%,50V,NPO,TP,1608
C315 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C32 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C33 2402-001008 C-AL,SMD;220uF,20%,4V,-,6.6x6.6x5.4mm,2
C331 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,- Hi8/PAL
C331 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,- Hi8/NTSC
C34 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
C35 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C355 2203-000405 C-CERAMIC,CHIP;180pF,5%,50V,NPO,TP,1608,
C36 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C37 2404-000335 C-TA,CHIP;3.3uF,20%,16V,-,TP,3216,-
C38 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C39 2404-000335 C-TA,CHIP;3.3uF,20%,16V,-,TP,3216,-
C4 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C40 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C401 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, NORMAL
C401 2203-000925 C-CERAMIC,CHIP;470nF,+80-20%,50V,Y5V,TP, Hi8
C41 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C42 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C43 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C44 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C45 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C451 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C452 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C453 2203-000681 C-CERAMIC,CHIP;27pF,5%,50V,NPO,1608,-,TP
C454 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C46 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C47 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C48 2203-000041 C-CERAMIC,CHIP;10pF,0.25pF,50V,NPO,TP,16
C49 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C5 2203-000315 C-CERAMIC,CHIP;120pF,5%,50V,NPO,TP,1608,
C50 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C501 2402-000198 C-AL,SMD;47uF,20%,16V,GP,TP,6.6x6.6x5.4
C502 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C503 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C505 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C506 2203-001640 C-CERAMIC,CHIP;390pF,10%,50V,X7R,TP,1608
C507 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1
C508 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1
C509 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C510 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C511 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C512 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C513 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
