Samsung Electronics 6-5
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
121 AD63-30588A COVER-FRONT(B);-,ABS94,HB,-,-,-,22X,VP-A VP-A800/SCA80
122 AD63-30584A COVER-JACK(C);-,TPE,-,-,BLK,-,-,VP-A850 SCA35/SCA85/VP-A34/VP-A850
AD63-30585A COVER-JACK(B);-,TPE,-,-,BLK,-,-,VP-A80 SCA80/VP-A800
123 AD63-70074A SHEET-MIC;-,HIMERON,-,-,-,-,-,VP-A850 ALL
124 AD63-40954A SHIELD-MIC(C);-,SPTE,T0.25,-,VP-A850 SCA35/SCA85/VP-A34/VP-A850
AD63-40956A SHIELD-MIC B;-,SPTE,T0.25,-,VP-A80 VP-A800/SCA80
125 AD98-12027C ASS’Y-MIC;VP-A850/XEU,STEREO(1),- SCA85/VP-A800/VP-A850/SCA80
AD98-12027L ASS’Y-MIC;SCL300,MONO SCA35/VP-A34
126 AD64-40691A WINDOW-REMOCON(C);-,PMMA,-,-,BLU,-,VP-A8 SCA85/VP-A800/VP-A850/SCA80
AD64-40691B WINDOW-REMOCON(C);-,PMMA,-,-,BLU,22X,MON SCA35/VP-A34
127 AD67-10203A LENS-HOOD(B);-,-,PA+ABS BLK,-,-,-,VP-A80 VP-A800/SCA80
128 AD64-10895A KNOB-POWER;-,PC+ABS,-,BLK,-,SC-L300 ALL
129 AD64-32018A CASE-FRONT(B);-,PC+ABS,94HB,-,-,-,-,VP-A VP-A800/SCA80
AD64-10896A BUTTON-LOCK;-,ABS94HB,-,-,-,SC-L300 SCA85/VP-A34/VP-A850/SCA35
131 AD61-21152A HOLDER-POWER;-,ABS,94HB,BLK,-,VP-A80 SCA30/SCA33/SCA80/VP-A30
VP-A31/VP-A33/VP-A800
132 AC90-10800H ASS’Y-MIC BOARD;SCA800,ST SCA80/VP-A800
136 AD63-30587A COVER-FRONT(C);-,ABS94,HB,-,-,-,22X,VP-A SCA35/SCA85/VP-A34/VP-A850
137 AD67-10204A LENS-HOOD(C);-,-,PC+ABS BLK,-,-,22X/BILC SCA35/SCA85/VP-A34/VP-A850
138 AD60-42042A RING-HOOD(AL);-,-,-,-,-,AL SCA35/SCA85/VP-A34/VP-A850
139 AD64-32017A CASE-FRONT(C);-,PC+ABS,94HB,-,-,-,-,VP-A SCA85/VP-A850
AD64-32029B CASE-FRONT(C);-,PC+ABS,94HB,-,-,-,S-JACK SCA35/VP-A34
140 AD63-32013A COVER-LENS TOP;-,PC+ABS,-,BLK,-,SC-L300, SCA35/SCA85/VP-A34/VP-A850
141 AD63-32014A COVER-LENS BOTTOM;-,PC+ABS,-,BLK,-,SC-L3 SCA35/SCA85/VP-A34/VP-A850
142 AD61-21139A HOLDER-COVER;-,PC+ABS,-,BLK,-,SC-L350 SCA35/SCA85/VP-A34/VP-A850
143 AD61-21140A HOLDER-RING;-,POM,-,-,-,SC-L350 SCA35/SCA85/VP-A34/VP-A850
144 AD90-10850K ASS’Y-FRONT BOARD;VP-A85/SCA85,EIS,REMOC SCA85/VP-A850
AD90-10850Z ASS’Y-FRONT BOARD;VP-L350,NOR,MONO,EIS SCA35/VP-A34
145 AD64-20624A MASK-LAMP;-,PC,-,-,CLR,VP-A85 SCA35/VP-A34/SCA85/VP-A850
146 4713-001007 LAMP-HALLOGEN;6V,500mA,3W,YEL,45Lm,-,4.8 SCA35/SCA85/VP-A34/VP-A850
147 AD98-12028B ASS’Y-LIGHT VP-A34/VP-A850/SCA35/SCA85
149 AC61-32047A PLATE-NUT;SECC,T0.8,-,-,SV-V40 SCA35/SCA85/VP-A34/VP-A850
151 AD63-30589A COVER-FRONT(A);-,ABS94,HB,-,-,-,16X,VP-A SCA30/SCA33/VP-A30/VP-A31
VP-A33
152 AD63-40955A SHIELD-MIC A;-,SPTE,T0.25,-,VP-A30 SCA30/SCA33/VP-A30/VP-A31
VP-A33
153 AD98-12027M ASS’Y-MIC;VP-A30,MONO/16X SCA30/SCA33/VP-A30/VP-A31
VP-A33
154 AD64-40692A WINDOW-REMOCON(A);-,PMMA,-,-,BLU,SILK(X) SCA30/SCA33/VP-A30/VP-A31
VP-A33
155 AD67-10202A LENS-HOOD(A);-,-,PA+ABS BLK,-,-,16X,VP-A SCA30/SCA33/VP-A30/VP-A31
VP-A33
156 AD64-32019A CASE-FRONT(A);-,ABS,94HB,-,-,-,-,VP-A30 VP-A30
AD64-32019B CASE-FRONT(A);-,ABS,94HB,-,-,-,P31/P33/N SCA30/SCA33/VP-A31/VP-A33
157 AD64-11020A BUTTON-LOCK;-,POM,-,RED,-,VP-A30 SCA30/SCA33/SCA80/VP-A30
VP-A31/VP-A33/VP-A800
158 AC90-10800E ASS’Y-MIC BOARD;SCA30,MO SCA30/VP-A30
AC90-10800F ASS’Y-MIC BOARD;SCA30,MO SCA33/VP-A31/VP-A33
194 AD61-21146A HOLDER-POWER;-,ABS94,HB,-,16X,SC-L350 SCA35/VP-A34/SCA85/VP-A850
195 AD61-60631A SPRING-COVER;-,-,SWPB,-,-,-,SC-L300 SCA35/VP-A34/SCA85/VP-A850
196 AD61-60601A SPRING-KNOB POWER;-,-,SUS304 WPB,-,-,-,- ALL
303 AD98-12028G ASS’Y-CASE FRONT;VP-A80,- SCA80/VP-A800
304 AD98-12026Y ASS’Y-CASE FRONT;VP-A85,22X/Hi8 SCA85/VP-A850
AD98-12028F ASS’Y-CASE-FRONT VP-A34/SCA35
305 AD98-12028C ASS’Y-CASE FRONT;VP-A30,- VP-A30
AD98-12028D ASS’Y-CASE FRONT;VP-A31,- SCA33/VP-A31/VP-A33
AD98-12028H ASS’Y-CASE FRONT;SCA30,- SCA30
903 AC60-10020A SCREW-MACHINE;BH,+,M2,X5,FZB,FE,UP,-,- ALL
904 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB ALL
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB ALL
906 AD60-00002A SCREW MACHINE;-,-,-,-,-,-,M2X4, -FH, FEN ALL
