Samsung SCA30 - Page 66

Samsung Electronics 6-7
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
133 AD63-62002A SPACER-CCD;-,SILICONE,T1,BLK,-,VP-A57 VP-A30/VP-A31/VP-A33/SCA30
SCA33
AD63-62008A SPACER-CCD VP-A34/VP-A800/VP-850/SCA35
SCA80/SCA85
134 AD29-92001D FILTER-OLP;SV-2C04MM,KSS,SPACE,TR SCA30/SCA33/SCA35/VP-A30
VP-A31/VP-A33
AD29-92001E FILTER;SV-3C08MM,KSS,SPACE,TR SCA80/SCA85/VP-A34/VP-A800
VP-A850
135 AD61-12048A BRACKET-LENS;-,SUS T0.5,SC-L300 ALL
186 AD90-10847K ASS’Y-MAIN BOARD;VP-A85,PAL VP-A850
AD90-10847L ASS’Y-MAIN BOARD;SCA85,NTSC SCA85
AD90-10848N ASS’Y-MAIN BOARD;VP-A80,PAL VP-A800
AD90-10848P ASS’Y-MAIN BOARD;VP-A34,PAL VP-A34
AD90-10848Q ASS’Y-MAIN BOARD;VP-A33,PAL VP-A33
AD90-10848R ASS’Y-MAIN BOARD;VP-A30,PAL VP-A30
AD90-10848S ASS’Y-MAIN BOARD;SCA35,NTSC SCA35
AD90-10848T ASS’Y-MAIN BOARD;SCA33,NTSC SCA33
AD90-10848U ASS’Y-MAIN BOARD;SCA30,NTSC SCA30
AD90-10854M ASS’Y-MAIN BOARD;VP-A31,PAL VP-A31
AD97-00274A ASS’Y--MAIN BOARD;SCA800,-,- SCA80
187 AD94-00005A ASS’Y-FPC,C;A3/S3,ROTARY-FPC ALL
188 AD61-00054A CHASSIS-BOTTOM;-,STS,-,0.6,-,-,VP-A850 ALL
189 AD90-10832B ASS’Y-FPC DECK;VP-A20,DECK ALL
190 AD61-11074A CHASSIS-TOP;-,STS,-,T0.6,-,-,VP-A85 ALL
191 AD98-12027D ASS’Y-CASE TOP;SC-L300,- ALL
193 AD97-00592A ASS’Y-CAMERA;A3,-,X22,570K,SAMSUNG VP-A34/VP-A850
AD97-00594A ASS’Y-CAMERA;-,-,X22,470K,SAMSUNG VP-A800/SCA80/SCA85
AD97-00595A ASS’Y-CAMERA;A3,-,X22,270K,SAMSUNG SCA35
AD90-10854T ASS’Y-CAMERA;VP-A30,PAL VP-A30/VP-A31/VP-A33
AD90-10854W ASS’Y-CAMERA;SCA30,NTSC SCA30/SCA33
197 AD97-00596A ASS’Y-LENS;A3,-,X22,NORMAL,SAMSUNG SCA35
AD97-00597A ASS’Y-LENS;-,-,X22,HI8,SAMSUNG VP-A34/VP-A800/VP-A850
SCA80/SCA85
AD90-10854B ASS’Y-LENS;X16,LENS VP-A30/VP-A31/VP-A33
SCA30/SCA33
198 AD90-10849X ASS’Y-CCD BOARD;VP-A85,Hi8,EIS VP-A34/VP-A850
AD90-10849Y ASS’Y-CCD BOARD;SCA85,Hi8,EIS VP-A800/SCA80/SCA85
AD97-00076A ASS’Y--CCD;A3,PAL,-,- VP-A30/VP-A31/VP-A33
AD97-00077A ASS’Y--CCD;A3,NTSC,-,- SCA30/SCA33
AD97-00232A ASS’Y--CCD;270K,X22,-,- SCA35
500 AD97-00282A ASS’Y-DECK SCA30/SCA33/SCA35/SCA80
SCA85
AD97-00283A ASS’Y-DECK VP-A30/VP-A31/VP-A33/VP-A34
VP-A800/VP-A850
901 AC60-10017A SCREW-MACHINE;BH,+,M1.7,X3.5,FEFZY,SWCH1 ALL
904 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB ALL
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB ALL
907 AC60-10024A SCREW-MACHINE;BH,+,M2,X3,FZW,FE,-,-,- ALL
