Samsung SCA30 - Page 70

Samsung Electronics 6-11
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
300 AC90-10012V ASS’Y-CRT;CS96(SPORTS),- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
301 AD98-11265G ASS’Y-EVF LENS;A3-PJ,B/W SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
302 AC67-12070A LENS-EVF(MD);PMMA D19.1 ASP,-,-,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
303 AD61-22029A HOLDER-LENS A;-,ABS94,HB,BLK,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
304 AD90-10850M ASS’Y-EVF BOARD;SC-L350,NTSC -A3/S3/CS99 SCA30
AD90-10850N ASS’Y-EVF BOARD;VP-L350,PAL-A3/S3/CS99 VP-A30/VP-A31/VP-A34/VP-A800
VP-A850
305 AC67-10066A LENS-EVF GJ;-,OPT,GRASS-F1,D11.5,-,CG819 SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
306 AD61-21142A HOLDER-LENS B;-,ABS94,HB,BLK,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
407 AD73-10049A RUBBER-EYE CUP;TPR BLK,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
408 AD61-50783A GUIDE-LOCK;-,ABS94,HB,-,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
409 AD61-50782A GUIDE-CAP;-,ABS94,HB,-,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
410 AD61-60632A SPRING-EVF;-,-,SUS304 T0.3,-,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
413 AD60-42038A RING-EVF;-,ABS94,HB,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
414 AD60-42039A RING-GUIDE;-,ABS94,HB,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
415 AD61-20918B CAP-FOCUS;-,MBR,-,BLK,-,VP-K70 SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
416 AD64-32009A CASE-EVF R;-,ABS94,V0,-,-,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
417 AD66-80164A LINK-EVF;-,POM,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
418 AD61-50781A SHAFT-LOCK;-,C3602BD,-,-,-,-,- SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
420 AD64-32008A CASE-EVF L;-,ABS94,V0,-,-,B/W,NTSC,SCA3 SCA30
AD64-32008C CASE-EVF L;VP-A850,ABS94,V0,16X,B/W,PAL, VP-A30/VP-A31/VP-A34/VP-A800
VP-A850
421 AD61-00032A PLATE--EVF;-,-,-,SECC-P, T0.8,A3-PJ SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
904 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
906 AD60-00002A SCREW MACHINE;-,-,-,-,-,-,M2X4, -FH, FEN SCA30/VP-A30/VP-A31/VP-A34
VP-A800/VP-A850
