Samsung SCA30 - Page 72

Samsung Electronics 6-13
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
401 AD61-21045A HOLDER-LCD;-,PC/ABS,VO,-,-,VP-A20 SCA33/SCA35/SCA80/SCA85
VP-A33
402 AC07-10001L LCD DISPLAY;LCX005BKB,COLOR,537x227,0.5 SCA33/SCA35/SCA80/SCA85
VP-A33
403 AD61-50708A GUIDE-LIGHT;-,ABS94V0,-,T1.5,BLK,-,SV-S9 SCA33/SCA35/SCA80/SCA85
VP-A33
404 AD90-10850J ASS’Y-B/L BOARD;A3-P/J,NTSC,PAL SCA33/SCA35/SCA80/SCA85
VP-A33
405 AD61-21045A HOLDER-LIGHT;-,ABS94,HB,BLK,-,SV-S99 SCA33/SCA35/SCA80/SCA85
VP-A33
406 AD98-11265J ASS’Y-CVF LENS;VP-A20,BW SCA33/SCA35/SCA80/SCA85
VP-A33
407 AD73-10049A RUBBER-EYE CUP;TPR BLK,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
408 AD61-50783A GUIDE-LOCK;-,ABS94,HB,-,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
409 AD61-50782A GUIDE-CAP;-,ABS94,HB,-,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
410 AD61-60632A SPRING-EVF;-,-,SUS304 T0.3,-,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
411 AD67-10196A LENS-EVF;-,-,PMMA,-,-,CLR,- SCA33/SCA35/SCA80/SCA85
VP-A33
412 AD61-22030A HOLDER-LENS;-,ABS94,HB,-,-,VP-A20 SCA33/SCA35/SCA80/SCA85
VP-A33
413 AD60-42038A RING-EVF;-,ABS94,HB,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
414 AD60-42039A RING-GUIDE;-,ABS94,HB,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
415 AD61-20918B CAP-FOCUS;-,MBR,-,BLK,-,VP-K70 SCA33/SCA35/SCA80/SCA85
VP-A33
416 AD64-32009A CASE-EVF R;-,ABS94,V0,-,-,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
417 AD66-80164A LINK-EVF;-,POM,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
418 AD61-50781A SHAFT-LOCK;-,C3602BD,-,-,-,-,- SCA33/SCA35/SCA80/SCA85
VP-A33
419 AD90-10850G ASS’Y-CVF BOARD;A3-P/L,PAL VP-A33
AD90-10850H ASS’Y-CVF BOARD;A3-P/L,NTSC SCA33/SCA35/SCA80/SCA85
420 AD64-32008B CASE-EVF L;SCA85,ABS94,V0,X22.COLOR,NTS SCA33/SCA35/SCA80/SCA85
AD64-32008D CASE-EVF L;VP-A85,ABS94,V0,22X,COLOR,PAL VP-A33
421 AD61-00032A PLATE--EVF;-,-,-,SECC-P, T0.8,A3-PJ SCA33/SCA35/SCA80/SCA85
VP-A33
904 AC60-10055A SCREW-TAPPING;BH,+,-,M2,X4,FZB SCA33/SCA35/SCA80/SCA85
VP-A33
905 AC60-10054A SCREW-TAPPING;BH,+,-,M2,X6,FZB SCA33/SCA35/SCA80/SCA85
VP-A33
906 AD60-00002A SCREW MACHINE;-,-,-,-,-,-,M2X4, -FH, FEN SCA33/SCA35/SCA80/SCA85
VP-A33
