Samsung Electronics 6-15
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
001 AC60-12083A SCREW-MACHINE;B,BH,-,M1.7,L5,FE,WHT,-,-
002 AD60-10500E SCREW-MACHINE;-,BWSH,+,UP,M2,L5,ZPCNYLOK
003 AD60-10500D SCREW-MACHINE;-,BWSH,+,UP,M2,L7,ZPCNYLOK
004 AC60-10017A SCREW-MACHINE;BH,+,M1.7,X3.5,FEFZY,SWCH1
005 AC60-12112A SCREW-BH;-,BH,+,M1.4,L2,-
021 AC60-30015A WASHER-SLIT;ID 1.1,OD 2.6,T 0.4,POLYSLID
301 AD96-10473P ASS’Y-HOUSING;DE-6B,-
302 AD96-10471Z ASS’Y-DRUM;DE6A-PH-SS,- VP-A30/VP-A31/VP-A33/VP-A34
VP-A800/VP-A850
AD96-10471Y ASS’Y-DRUM;DE6A-NH-SS,- SCA30/SCA31/SCA33/SCA35
SCA80/SCA85
303 AD66-40153A ROLLER-IMP ASS’Y;-,YF-10,OD7,-,DE-6
304 AC61-72009A CONTACT-EARTH BRUSH;SECC/PBSP/CR/C,-,-,-
305 AC63-32091A COVER-DRUM;DURACON(M90-44),-,-,-,-,-,DE-
401 AC63-30009A COVER-REEL ASS’Y;ABS 95,HB,-,-,-,-,DE-6,-
402 AC66-12035A IDLER-ASS’Y;-,-,DE-6
