Samsung Electronics 7-7
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
C818 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C819 2203-001554 C-CERAMIC,CHIP;1.8nF,10%,50V,X7R,TP,1608
C820 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,
C821 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C822 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,
C823 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C824 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C825 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C826 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C827 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C828 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C829 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C9 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C901 2404-000128 C-TA,CHIP;10uF,20%,16V,-,TP,6032,-
C902 2203-002376 C-CERAMIC,CHIP;2.2uF,+80-20%,50V,Y5V,TP,
C903 2203-001724 C-CERAMIC,CHIP;4700NF,+80-20%,16V,Y5V,TP
C904 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
C905 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C906 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C907 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C908 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C909 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C910 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C911 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C912 2203-002376 C-CERAMIC,CHIP;2.2uF,+80-20%,50V,Y5V,TP,
C913 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
C914 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
C915 2203-002376 C-CERAMIC,CHIP;2.2uF,+80-20%,50V,Y5V,TP,
C916 2203-000483 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C917 2203-000483 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C920 2203-000483 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C921 2203-000483 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C922 2203-001724 C-CERAMIC,CHIP;4700NF,+80-20%,16V,Y5V,TP
C923 2404-000304 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C924 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C925 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
C926 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C927 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C928 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C929 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C930 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C931 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
C932 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,TP,1608,1
C933 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C934 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C935 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C936 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C937 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C938 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C939 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C940 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C941 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C942 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C943 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C944 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
CG03 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CG04 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CG05 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CN001 3708-001345 CONNECTOR-FPC/FC/PIC;11P,-,SMD-A,SN
CN501 3710-001301 CONNECTOR-SOCKET;48P,2R,0.8mm,SMD-S,SN
CN601 3710-000551 CONNECTOR-SOCKET;24P,2R,1.0MM,SMD-S,SN
CN603 3711-000386 CONNECTOR-HEADER;3WALL,10P,1R,1.25mm,SMD
CN604 3708-000457 CONNECTOR-FPC/FC/PIC;15P,1.25mm,SMD-S,SN
CN605 3710-001479 CONNECTOR-SOCKET;14P,2R,1MM,SMD-S,SN
CN801 3708-001025 CONNECTOR-FPC/FC/PIC;30P,0.5mm,ANGLE,SN
CN802 3711-000556 CONNECTOR-HEADER;BOX,12P,1R,1.25mm,SMD-A
CN851 3711-002127 CONNECTOR-HEADER;BOX,8P,1R,1.25mm,SMD-A,
CNP01 3710-001478 CONNECTOR-SOCKET;18P,2R,1MM,SMD-S,SN
CNP02 3708-001070 CONNECTOR-FPC/FC/PIC;22P,0.5MM,SMD-A,SN
CNP03 3708-001069 CONNECTOR-FPC/FC/PIC;20P,0.5MM,SMD-A,SN
CP01 2404-000156 C-TA,CHIP;1uF,20%,35V,-,TP,3528,1.4mm
CP02 2203-005148 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608
CP03 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
CP04 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
CP05 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP06 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608
CP07 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,
CP08 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
CP09 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP10 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP100 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP101 2203-000426 C-CERAMIC,CHIP;18pF,5%,50V,NPO,1608,-,TP PAL
CP101 2203-000681 C-CERAMIC,CHIP;27pF,5%,50V,NPO,1608,-,TP NTSC
CP102 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
CP104 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP105 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP110 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP111 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP12 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CP129 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
CP13 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CP14 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608,
CP15 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
CP16 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP17 2404-000190 C-TA,CHIP;22uF,20%,16V,-,TP,5832,-
CP18 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP19 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP20 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP21 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
