Samsung SCA30 - Page 87

Samsung Electronics 7-9
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
L1 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L101 2703-000425 INDUCTOR-SMD;27uH,5%,2x2.5x1.8mm
L102 2703-000380 INDUCTOR-SMD;18uH,5%,3.2x2.5x2.2mm
L103 2703-000380 INDUCTOR-SMD;18uH,5%,3.2x2.5x2.2mm
L104 2703-000425 INDUCTOR-SMD;27uH,5%,2x2.5x1.8mm
L105 2703-000349 INDUCTOR-SMD;120uH,5%,3.2x2.5x2.2mm
L106 2703-000371 INDUCTOR-SMD;4.7uH,5%,2.5x2x1.8mm
L107 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L108 2703-000370 INDUCTOR-SMD;47uH,5%,2.5x2x1.8mm
L109 2703-000187 INDUCTOR-SMD;3.3uH,5%,2x2.5x1.8mm
L110 2703-000380 INDUCTOR-SMD;18uH,5%,3.2x2.5x2.2mm
L111 2703-000371 INDUCTOR-SMD;4.7uH,5%,2.5x2x1.8mm
L141 2703-000365 INDUCTOR-SMD;15uH,5%,2.5x2x1.8mm
L142 2703-000374 INDUCTOR-SMD;6.8uH,5%,2.5x2x1.8mm
L143 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
L2 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L202 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L203 2703-000372 INDUCTOR-SMD;56uH,5%,2.5x2x1.8mm
L204 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L238 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L251 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L252 2703-000349 INDUCTOR-SMD;120uH,5%,3.2x2.5x2.2mm
L253 2703-000417 INDUCTOR-SMD;220uH,5%,3.2x2.5x2.2mm
L291 2703-000366 INDUCTOR-SMD;22uH,5%,2.5x2x1.8mm
L311 2703-000380 INDUCTOR-SMD;18uH,5%,3.2x2.5x2.2mm
L312 2703-000425 INDUCTOR-SMD;27uH,5%,2x2.5x1.8mm
L331 2703-000372 INDUCTOR-SMD;56uH,5%,2.5x2x1.8mm
L4 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L401 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L451 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L452 2703-000365 INDUCTOR-SMD;15uH,5%,2.5x2x1.8mm
L502 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
L503 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L6 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L601 2703-000409 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm
L701 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L702 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L710 2703-000425 INDUCTOR-SMD;27uH,5%,2x2.5x1.8mm
L901 2703-000402 INDUCTOR-SMD;1uH,20%,3.2x2.5x2.2mm
L902 2703-000408 INDUCTOR-SMD;3.3uH,20%,3.2x2.5x2.2mm
L903 2703-000414 INDUCTOR-SMD;22uH,20%,7x7x3.2mm
L904 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L905 2703-000400 INDUCTOR-SMD;15uH,10%,3.2x2.5x2.2mm
L906 2703-000400 INDUCTOR-SMD;15uH,10%,3.2x2.5x2.2mm
L907 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L908 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L909 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L910 2703-000408 INDUCTOR-SMD;3.3uH,20%,3.2x2.5x2.2mm
L911 2703-001194 INDUCTOR-SMD;100uH,20%,7x7x3.2mm
L912 2703-001194 INDUCTOR-SMD;100uH,20%,7x7x3.2mm
IC001 1201-001091 IC-PREAMP;2002,QFP,48P,-,SINGLE,1000MV/V Hi8
IC001 1201-001312 IC-PREAMP;CXA2032Q,QFP,32P,7.0MIL,SINGLE NORMAL
IC002 1209-001044 IC-DELAY LINE;CXL5517N,SOP,20P,173MIL,PL PAL
IC002 AC14-12014E IC-CCD;CXL5502N,DIP,- NTSC
IC004 1209-001052 IC-ETC, LINEAR;CXA2003N,SOP,24P,-,PLASTI
IC101 1201-001092 IC-RF AMP;1509,QFP,48P,-,SINGLE,-,PLASTI
IC201 AD14-12001D IC-VIDEO PROCESS;CXA2085R,LQFP,64P Hi8
IC201 AD14-12001E IC-VIDEO PROCESS;CXA2081R,LQFP,64P,NOR NORMAL
IC202 AD14-00001A IC--VIDEO PROCESS;CXA2083R,VQFP,64P
IC401 1002-001125 IC-D/A CONVERTER;M62366GP,8BIT,SSOP,20P,
IC451 1204-001458 IC-OSD PROCESSOR;M35040-064FP(SEC),DIP,2
IC501 1204-001124 IC-VIDEO SYSTEM;CXA1814N,SOP,30P,-,PLAST
IC502 1003-001188 IC-MOTOR DRIVER;LB1990W,QFP,64P,400MIL,S
IC503 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
IC601 AD09-00021A IC-MCU;CXP87140-126R,-,TRAY,-,8BIT,100P PAL
IC601 AD09-00022A IC-MCU;CXP87140-125R,-,TRAY,-,8BIT,100P NTSC
IC701 1201-001406 IC-AUDIO AMP;7458,SQFP,64P,393MIL,-,-,PL
NORMAL/MONO
IC701 1204-001416 IC-AUDIO PROCESSOR;LA74000W,QFP,64P,-,PL Hi8/STEREO
IC801 1201-001108 IC-AUDIO AMP;7471,SOP,36P,-,SINGLE,-,PLA
IC901 1203-001534 IC-PWM CONTROLLER;TL1466I,QFP,64P,-,PLAS
ICP01 AD14-10002D IC-DSP;KS7331,VQFP,128P
ICP02 AD09-00016A IC-MICOM;P81840A-519R,X16,2ND,100,TRAY,- X16
ICP02 AD09-00024A IC-MICOM;P81840A-521R,X22,4TH,100,TRAY,- X22
ICP03 1002-001127 IC-A/D CONVERTER;AD9803,10BIT,LQFP,48P,3
ICP04 1003-001200 IC-MOTOR DRIVER;UPD16835,SOP,38P,300MIL,
ICP06 1201-000240 IC-OP AMP;2902,SOP,14P,173MIL,QUAD,15V/m
ICP07 1201-000246 IC-OP AMP;3403,SOP,14P,173MIL,QUAD,20V/m
ICP08 1003-001065 IC-CLOCK DRIVER;KS7221D,SOP,20P,225MIL,Q
ICP09 1203-001021 IC-VOLTAGE REGULATOR;8423,SOP,8P,251MIL,
ICP10 1103-001134 IC-EEPROM;24C040,512x8BIT,SOP,8P,150MIL,
ICP11 0801-002417 IC-CMOS LOGIC;TC7SU04F,INVERTER,SSOP,5P
ICW01 AD14-10002E IC-WDR;KS7332,QFP,48P
L001 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm Hi8
L001 2703-000404 INDUCTOR-SMD;220uH,10%,3.2x2.5x2.2mm NORMAL
L002 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm Hi8
L002 2703-000404 INDUCTOR-SMD;220uH,10%,3.2x2.5x2.2mm NORMAL
L003 2703-000404 INDUCTOR-SMD;220uH,10%,3.2x2.5x2.2mm Hi8
L003 2703-001758 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm NORMAL
L004 2703-000404 INDUCTOR-SMD;220uH,10%,3.2x2.5x2.2mm
L031 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm NORMAL
L031 2703-000385 INDUCTOR-SMD;330uH,5%,3.2x2.5x2.2mm Hi8
L032 2703-000388 INDUCTOR-SMD;470uH,5%,3.2x2.5x2.2mm
L033 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L034 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm
L041 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm
L042 2703-000372 INDUCTOR-SMD;56uH,5%,2.5x2x1.8mm
L043 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
L051 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L052 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
L061 2703-000367 INDUCTOR-SMD;33uH,5%,2.5x2x1.8mm
