Samsung SCA30 - Page 89

Samsung Electronics 7-11
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
QP05 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP06 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP09 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP10 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP11 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP12 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP15 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP16 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
R001 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R002 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608 Hi8
R002 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608 NORMAL
R003 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608 NORMAL
R003 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 Hi8
R004 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608 NORMAL
R004 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 Hi8
R005 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 Hi8
R005 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608 NORMAL
R006 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R007 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 NORMAL
R007 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608 Hi8
R008 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 NORMAL
R008 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608 Hi8
R009 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608 NORMAL
R009 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608 Hi8
R010 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 Hi8
R010 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608 NORMAL
R011 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 Hi8
R011 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 NORMAL
R012 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 NORMAL
R012 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608 Hi8
R013 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R014 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R015 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 NORMAL
R015 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608 Hi8
R016 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608 Hi8
R016 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608 NORMAL
R017 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608 NORMAL
R017 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608 Hi8
R018 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R019 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R020 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R021 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R022 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R023 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R024 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608 NORMAL
R024 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608 Hi8/PAL
R025 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R026 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608
R027 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R031 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R032 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R033 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R034 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R035 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608 Hi8
R035 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608 NORMAL
R036 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608 Hi8
R036 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 NORMAL
R037 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R038 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R039 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R040 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R041 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R042 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R043 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R044 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R045 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R046 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R049 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R050 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R051 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 Hi8
R051 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608 NORMAL
R052 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R053 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608 NORMAL/PAL
R053 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
NORMAL/NTSC
R054 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608 NORMAL/NTSC
R054 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608 NORMAL/PAL
R055 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R056 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R057 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R058 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R059 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R060 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R061 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R071 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R072 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R073 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R1 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R101 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R102 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R103 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R104 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R105 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R106 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R107 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R108 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R109 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R110 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R111 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R112 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R113 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
