Samsung SCX-4216F Service Manual

7-22
TROUBLESHOOTING
Samsung Electronics
Service Manual
7.6.1 Defective PC Scan
• Description The PC Scan is not functioning at all.
7.6 Scanning Problems
Check and Cause Solution
1. Check the Cable (USB or Parallel)
2. Check if the driver is installed properly.
3. Check if copy function operates normally.
1. If the PC and the cable are not connected properly,
reconnect it.
2. After confirming that it is proper by performing a PC
printing test related to driver setup, if it is not so, rein-
stall it. (Refer to User's Manual.)
3. If copy function works, replace the Main PBA.
If copy function doesn’t work, replace the CCD Ass’y
and try again.
7.6.2 Defective Image Quality of PC Scan
• Description The image PC scanned is not clear or bad.
Check and Cause Solution
1. Check the waveform form by performing a CCD
test in TECH mode.
2. Check if the resolution is set too low in PC Scan
options. (Refer to User's Manual.)
1. If the CCD waveform form is abnormal, try to replace
the CCD ASS’Y.
2. If the resolution is set to low, let the user be acquaint-
ed with the using method well.

Samsung SCX-4216F Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	16 ppm
Internal memory	8 MB
Input color depth	24 bit
Copy speed (black, normal quality, A4)	16 cpm
Modem speed	33.6 Kbit/s
Maximum input capacity	250 sheets
Dimensions (WxDxH)	474 x 436 x 417 mm
Page description languages	SPL
Market positioning	Home & office
