Samsung SCX-4216F Service Manual

7-7
Samsung Electronics
TROUBLESHOOTING
Service Manual
7.2.6 Cover Open
• Description
The ERROR lamp is on even when the print cover is closed.
Check and Cause Solution
1. The hook lever in the top cover may be defective.
2. Check the connector (CN1 : Engine B’d↔HVPS) and
circuit of the cover switch department in the Main Control
board. Perform DCU mode : If Error state '64' occurs,
Check the related codes of the Cover Open Error.
1. Replace the hook lever, if defective.
2. Check the insertion of the Cover Open S/W
Connect.
3. Replace the Main Control board or Cover Open
S/W.
7.2.7 No lamp on when the cover is open
• Description
The ERROR lamp does not come on even when the printer cover is open
Check and Cause Solution
1. Check the connector(CN8) and circuit of the cover switch
department in the Main Control board. Perform DCU
mode : If Error state '64' occurs, Check the related codes
of the Cover Open Error
1. Check the insertion of the Cover Open S/W
Connect.
2. Replace the Main Control board or Cover Open
S/W.

Samsung SCX-4216F Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	16 ppm
Internal memory	8 MB
Input color depth	24 bit
Copy speed (black, normal quality, A4)	16 cpm
Modem speed	33.6 Kbit/s
Maximum input capacity	250 sheets
Dimensions (WxDxH)	474 x 436 x 417 mm
Page description languages	SPL
Market positioning	Home & office
