English _1

English

SAMSUNG ALL-IN-ONE SECURITY SYSTEM

KIT MODEL

SDS-P3042 / V3042/ S3042/ P3022/ P4042 / V4042/

S4042/ P4082/ P5082 / S5082 / P5102 / P5122

DVR MODEL

SDR-3102

/

4102

/

5102

Quick Start Guide

Thank you for purchasing a Samsung DVR Security System.

Follow the simple steps in this guide to set up and start using your new system.

If you have any questions or need help installing your new product please contact our free technical support.

Telephone: 1-877-349-3149

9am - 9pm EST, Monday - Friday

Internet: http://www.samsungsv.com

INSTALLING YOUR SYSTEM

M

 Images may differ depending on the model.

❒

4CH DVR

Front

Rear

1

Connect a mouse

4

Connect the DC adaptors

2

Connect a camera

5

Connect to a network router

3

Connect a monitor

POWER REC NETWORK

1

IN1

IN3

IN4

AUDIO IN

AUDIO OUT

VGA

IN2

HDMI

eSATA

VIDEO IN

LAN

USB

RS485

DC12V

2

3

4

5

Table of Contents

Other manuals for Samsung SDS-P5122

User Manual146 pages

Questions and Answers:

Z
Zachary CervantesSep 12, 2025
How to improve the image quality of recording data on a Samsung SDS-P5122 Security System?
- J
  Jennifer FoxSep 12, 2025
  To improve the image quality of recorded data on your Samsung Security System, increase the resolution and quality level in Menu – Record – Quality / Resolution. Select a bigger size when specifying the recording size (WD1>4CIF>2CIF>CIF) and specify a bigger level for the recording quality. Keep in mind that increasing the resolution and recording quality will increase the data size, filling the HDD faster.
S
Scott AdamsAug 25, 2025
Why is my Samsung DVR not recording?
- M
  Melissa ConnerAug 25, 2025
  If your player does not display a Live image at all, that indicates recording does not work, so first check if you see an image on the screen. Recording does not work if the recording settings are not properly configured. To start recording manually, press the [REC] button on the remote control. To schedule recording, specify a desired time in Menu – Record – Recording Schedule. Continuous Recording will proceed in any conditions at the specified time. Event Recording will perform only if the event is of alarm, motion detection, video loss and Tampering Detection. If there is no event found, Continuous recording will perform. Whereas, if an event occurs, Event recording will perform.
Q
qjonesAug 25, 2025
How to improve the recording quality on my Samsung DVR?
- M
  monique18Aug 26, 2025
  To enhance the image quality of your recorded data, increase the resolution and quality level in Menu – Record – Quality / Resolution. You can select a bigger size when specifying the recording size and specify a bigger level for the recording quality.
A
Andrew MartinezAug 26, 2025
Why can't I play backup data from my Samsung DVR on my PC?
- J
  John ZamoraAug 27, 2025
  When you are backing up data, you have choices about the player either: PC or DVR. Make your selection before proceeding. If you are using the PC to play the data, the format of the backup file should be SEC. If you are using the DVR for this purpose, formatting backup files should be done by the DVR.
R
robinsonaliciaAug 27, 2025
Why doesn't my Samsung Security System DVR recognize all the installed HDDs?
- B
  Brittany McdonaldAug 27, 2025
  If the DVR does not recognize all installed disks when you have connected multiple external HDDs to the Samsung Security System, it may take time for the DVR to recognize them. Try again in a moment. If the problem persists, it may be due to a mechanical error of the HDD installed. Try again with a different HDD.
A
Amy LopezSep 8, 2025
Why is the time bar missing in Search mode on my Samsung DVR?
- D
  denise70Sep 9, 2025
  The timeline can switch between normal and extension mode. Switch to normal mode or use the left or right button to navigate through the time bar.
B
Benjamin AdamsSep 7, 2025
Why is the Channel button not working on my Samsung DVR Live screen?
- C
  Christine MoodySep 7, 2025
  The Channel button does not work if the current screen is in the event monitoring mode. Press the [ALARM] button to exit the screen and select a channel.
J
Jessica SchwartzSep 8, 2025
Why can't I move the cursor to the Start button in calendar search on my Samsung DVR?
- M
  Marcus MccallSep 8, 2025
  Check if the channel and the date that you want to play are marked with the V symbol.
J
josephsuttonSep 2, 2025
Why doesn't my Samsung DVR recognize all of my external HDDs?
- C
  Christine SmithSep 2, 2025
  It takes time for the DVR to recognize multiple external HDDs, so try again in a moment. The problem may occur due to a mechanical error of the HDD installed, so try again with a different HDD.
S
Samantha RodriguezAug 31, 2025
What does NO HDD icon mean on my Samsung DVR?
- M
  Matthew BeardAug 31, 2025
  Check the HDD for connection. If the problem persists in a normal condition, contact the nearest service center to have the HDD checked by the service personnel.
