Samsung SR-686EV - 11-4 Disassemble of cooling part in the freezing room

11-4 Disassemble of cooling part in the freezing room
46 Samsung Electronics
1) Pull out the shelf.
2) Remove screws of evap cover and pull apart.
3) Disconnect the each terminal of wire housing
on top of the left side.
4) Remove screws of evap. Cover rear and
release the locking point using (-) driver.
Residual spread preventer
1
2
