With the door opened
1. Removethe3screwsholdingdowntheTOP
TABLE(1)andseparatetheconnectedwires.
1
2. Disconnectthetwoconnectors(2)onthe
leftsidedoor.Toremovethewatercoupler
fromthehinge,twistandpullitfromthehinge.
Removethewaterline(3)whilepressingthe
markedpart(4)ofthewaterlinecoupler.
2
3
4
3. Pullandremovethehingelever(5).
Removethegroundscrew(6) attached
totheupperleftdoorhingeswithaphilips
screwdriver(+).Removetheupperleftand
rightdoorhinges(7).
5
6
7
4. Liftthedoorstraightuptoremove.
5. Removethescrew(8)attachedtothe
lowerleftandrightdoorhingeswithaphilips
screwdriver(+).
Removethe2hexheadbolts(9) attached
tothelowerleftandrightdoorhingeswithan
allenwrench(5mm).
Removethelowerleftandrightdoorhinges
(10).
Allen wrench
10
8
9
