English - 45
OPERATING
RECOMMENDED LOCATION
FOR THE FOLDABLE SHELF
TheFoldableShelffoldsupfromthecenter,giving
youmorestorageareafortallitemswithoutyour
havingtore-arrangetheshelves.
• InstalltheFoldableShelfontherightsideof
therefrigerator.
• IfyouinstalltheFoldableShelfontheleftside,
theicemakerwillpreventtheshelffromfolding
completely.
• Touse,pushthefrontportionoftheshelf
backgentlysothattheshelffoldsupfromthe
middle.
touch
Recommended
Location
REMOVING THE
REFRIGERATOR
ACCESSORIES
1. Door Bins
• DoorBins(1)
To remove-Simplyliftthebinupandpull
straightout.
To relocate-Slideitinabovethedesired
locationandpushdownuntilitstops.
• DoorBins(2)
To remove-Taketherightsideofthebin
outbyliftingitatananglealongtheguide,
andthentaketheleftsideoutbypullingit
fromthedoor.
To relocate-Slideitintotheoriginallocation
andpushdownuntilitsticks.
• SparklingWatermodeldoorbins(2)
To remove-Taketherightsideofthebin
outbyliftingitatananglealongtheguide,
andthentaketheleftsideoutbypullingit
fromthedoor.
To relocate-AlignthepositionsoftheDoor
Bin’sholescarefully,andthenslidethebinin
abovethedesiredlocationandpushdown
untilitstops.
- Whenremovingandre-assemblingtheBottom
DoorBinoftheSparklingWatermodel,open
theCylinderCoverandtilttheCylindertowards
thefrontrst.
3
1
2
• SparklingWatermodeldoorbins(3)
DonotremoveSparklingWatermodeldoor
bin(3).Toclean,wipeitcompletelywitha
cleanclothwithoutremovingit.
Donotremovedoorbins(3).
Donotadjustabinfulloffood.
Removethefoodrst.
Toremovedustfromthebins,removetheguard
andwashinwater.
Injuriescanoccuriflargebottlesinthe
bottomdoorbinsfalloverwhenyouopen
thedoors.Openthedoorscarefully.
Injuriescanoccurifthedoorbinsarenot
rmlyconnectedtothedoors.
Donotallowchildrentoplaywiththebins.Sharp
cornersofthebinsmaycauseinjury.
2. Tempered Glass shelves
To remove-Tiltupthefrontoftheshelfinthe
directionshown(1)andliftitupvertically( 2).
Pulltheshelfout.
To re-install-Tiltthefrontoftheshelfupand
guidetheshelfhooksintotheslotsatadesired
height.Thenlowerthefrontoftheshelfsothatthe
hookscandropintotheslots.
1
2
TheTemperedGlassshelvesareheavy.
Usespecialcarewhenremovingthem.
CAUTION
CAUTION
CAUTION
DA68-02915A-11.indd 45 2015. 5. 8. �� 8:52
