INSTALLING THE WATER
DISPENSER LINE
Awaterdispenserwithalterisoneofthehelpful
featuresonyournewrefrigerator.Tohelppromote
betterhealth,thewaterlterremovesunwanted
particlesfromyourwater.However,itdoesnot
sterilizeordestroymicroorganisms.Youmayneed
topurchaseawaterpurifyingsystemtodothat.
Inorderfortheicemakertooperateproperly,a
waterpressureof138~862kPaisrequired.
Undernormalconditions,a170cc(5.75oz.)cup
canbelledinabout10seconds.
Iftherefrigeratorisinstalledinanareawithlow
waterpressure(below138kPa),youcaninstall
aboosterpumptocompensateforthelow
pressure.
Afteryouhaveconnectedthewaterline,make
surethewaterstoragetankinsidetherefrigerator
isproperlylled.Todothis,pressthewater
dispenserleveruntilthewaterrunsfromthewater
outlet.
Waterlineinstallationkitsareincludewith
unit.Youcannditinfreezerdrawer.
Thenewhose-setssuppliedwiththe
appliancearetobeusedandthatold
hose-setsshouldnotbereused.
Parts for water line Installation
Waterlinexerandscrews Pipeconnector
Waterline
Connecting to the water supply line
1. First,shutoffthemainwatersupplyline.
2. Locatethenearestcold,drinkingwaterline.
3. FollowtheWaterlineInstallationInstructionsin
theinstallationkit.
CAUTION
Thewaterlinemustbeconnectedto
thecoldwaterpipe.Ifitisconnected
tothehotwaterpipe,itmaycausethe
puriertomalfunction.
Close Main
Water pipe
Close Main
Water pipe
No gap
4. Afterconnectingthewatersupplytothewater
lter,turnyourmainwatersupplybackon
anddispenseabout3Ltoclearandprimethe
waterlter.
Connecting the water line to the
refrigerator
1. Removethecapfromthewaterlineontheunit
andinsertthecompressionnutofthewater
lineintothewaterlineontheunit.
2. Connectthewaterlineontheunitwiththe
waterlineinthekit.
3. Tightenthecompressionnutontothe
compressiontting.Thereshouldbenogaps
between(A,B&C)
4. Turnwateronandcheckforanyleakage.
Onlyconnectthewaterlinetoadrinkable
watersource.Ifyouhavetorepairor
disassemblethewaterline,cutoff6.5mm
oftheplastictubingtomakesureyouget
asnug,leak-freeconnection.
