Header command
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘N’ 0x3C ERR
ERR : Error code that shows what occurred error is
• Auto Adjustment Control (PC, BNC Only)
• Function
Personal Computer controls PC system screen automatically.
• Get Auto Adjustment Status
None
• Set Auto Adjustment
Header command
ID
DATA
Length
DATA
CheckSum
0xAA 0x3D 1 Auto Adjust-
ment
Auto Adjustment : 0x00 (Always)
• Ack
Header command
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘A’ 0x3D
Auto Ad-
justment
• Nak
Header command
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘N’ 0x3D ERR
ERR : Error code that shows what occurred error is
• Video Wall Mode Control
• Function
Personal Computer converts Video Wall Mode of TV or Monitor when Video Wall is ON.
Only works with TV or Monitor where Video Wall is on.
Does not operate in MagicInfo
