• Get Video Wall Mode
Header command
ID
DATA Length
CheckSum
0xAA 0x5C 0
• Set Video Wall Mode
Header command
ID
DATA
Length
DATA
CheckSum
0xAA 0x5C 1 Video Wall
Mode
Video Wall Mode : Video Wall Mode code to be set on TV or Monitor
1 : Full
0 : Natural
• Ack
Header command
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘A’ 0x5C
Video
Wall
Mode
Video Wall Mode : same as above
• Nak
Header command
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘N’ 0x5C ERR
ERR : Error code that shows what occurred error is
• Safety Lock
• Function
Personal Computer turns Safety Lock function of TV or Monitor ON / OFF.
Can operate regardless of whether power is ON / OFF.
• Get Safety Lock Status
Header command
ID
DATA Length
CheckSum
0xAA 0x5D 0
• Set Safety Lock Enable / Disable
