English - 24
Specifications
Table 3. Specifications
Picture Tube
19" (48.2 cm) Full square type [18” (45.8 cm) Viewable]
Flat face, 90° Deflection
Dot pitch : 0.20 (Horizontal) / 0.24 (Diagonal)
Anti-reflection coating with anti-electrostatic properties
Medium-short persistence phosphor
Synchronization Horizontal: 30 kHz to 85 kHz (Automatic)
Vertical: 50 Hz to 160 Hz (Automatic)
Display Colors Unlimited Colors
Maximum Resolution Horizontal: 1600 Dots
Vertical: 1200 Lines
Active Display Horizontal: 13.85" ± 0.12” (352 ± 3 mm)
Vertical: 10.39" ± 0.12” (264 ± 3 mm)
(Active display size is dependent upon signal timing and image size selection.)
Input Signal, Terminated Video signal: Analog video 0.7 Vpp positive at 75
Ω
Separate sync.: TTL Level, positive or negative
Composite sync.: TTL Level, positive or negative
Sync-on-green: Composite sync 0.3 Vpp negative
(Video 0.7 Vpp positive)
Maximum Pixel Clock 135 MHz
Power Supply AC 100-240 V ± 10%, 60 Hz/50 Hz ± 3 Hz
Power Consumption 110 W (Maximum)
Dimensions/Weight
(W x D x H)
Unit: 18,4 x 18.3 x 19.0 inch; 51.8 Ibs (468 x 466 x 483 mm; 23.5 kg)
Carton: 22.5 x 25.8 x 22.8 inch; 61.3 lbs (572 x 656 x 580 mm; 27.8 kg)
(All measurements approximate)
Environmental
Considerations
Operating Temperature : 32
°
F to 104
°
F (0
°
C to 40
°
C)
Humidity : 10% to 80%
Storage Temperature : -4
°
F to 113
°
F(-20
°
C to 45
°
C)
Humidity : 5% to 95%
NOTE: Design and specifications are subject to change without prior notice.
Appendix
9550eApp.book Page 24 Thursday, December 30, 1999 10:19 AM
