Bend radius adequate
Hole has grommet
Bend radius too tight
Hole has sharp edges
Hole has no grommet
General Housekeeping
1. Capture all drill chips during drilling operations. Magnets, sticky tape, vacuums, physical barriers, etc. may all be
used to accomplish this task. Do not allow drill chips to fall onto electrical equipment, furnishings, heating ducts,
etc.
2. Remove excess sealant. Sealant should be debris/contaminant free (e.g. drill chips), consistent, and uniform in
appearance.
3. Clip excess wire tie protrusions.
Mounting
Mounting Position Considerations
DO
Lay all components out prior to installation to check for cable length and interference issues.
Choose a location which does not impede driver or co-driver entry.
Ensure location of the installed tablet does not block driver view (including mirrors and gauges) or interfere with
safe operation of the vehicleʼs controls.
Choose a location which is within easy reach of the driver or co-driver, and within normal line-of-sight.
Mount in the vehicle at a convenient height and angle for drivers and co-drivers to access.
Ensure that the placement of the tablet allows drivers and co-drivers to easily dock and undock the tablet.
Ensure the mounting surface is strong enough to support the RAM mount and Tab Active tablet.
Use the backing plate to secure the mount.
DO NOT
Do not mount the tablet in an area that may interfere with the deployment of an airbag.
Do not mount the tablet in a location that may impact the driver or co-driver in the event of an accident or sudden
stop.
Do not mount the tablet in dirty or wet areas.
Do not mount the tablet in areas of direct sunlight.
