Samsung VRF DVM S2 - Outdoor Unit Specifications - Advanced Components; Components and Piping (22-26 HP)

AM220AXVDGH1EU AM240AXVDGH1EU AM260AXVDGH1EU
AM100AXVDGH/EU AM100AXVDGH/EU AM100AXVDGH/EU
AM120AXVDGH/EU AM140AXVDGH/EU AM160AXVDGH/EU
- - -
- - -
Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
- HEAT PUMP HEAT PUMP HEAT PUMP
HP 22 24 26
Cooling(Rated) kW 61.6 68.0 73.0
Heating(Rated) kW 61.6 68.0 73.0
Heating(Max) kW 69.3 76.5 81.9
EA 40 43 47
Min. kW 30.8 34.0 36.5
Max.
kW 80.1 88.4 94.9
Cooling(Rated) A 42.51 49.10 51.54
Heating(Rated) A 30.79 35.25 36.72
Cooling(Rated) A 37.26 44.09 48.02
Heating(Rated) A 29.68 33.73 34.94
Minimum Ssc MVA 7.7 8.3 8.9
MCA A 48.0 52.0 55.0
MFA A 63 63 63
SEER W/W - - -
SCOP
W/W - - -
ŋs.c % - - -
ŋs.h
% - - -
SEER W/W - - -
SCOP
W/W - - -
ŋs.c % - - -
ŋs.h
% - - -
kW 35.1 36.6 40.3
Body - GI Steel Plate GI Steel Plate GI Steel Plate
Base - GI Steel Plate GI Steel Plate GI Steel Plate
- Fin & Tube Fin & Tube Fin & Tube
Fin - Al Al Al
Tube - Cu Cu Cu
- Anti-corrosion Anti-corrosion Anti-corrosion
-
Inverter Scroll x 2 Inverter Scroll x 2 Inverter Scroll x 2
kW x n
(6.67 x 1) x 2 (6.67 x 1) x 2
(6.67 x 1) x 1 + (8.93 x 1) x 1
- (DS4GR7066FV* x 1) x 2 (DS4GR7066FV* x 1) x 2
(DS4GR7066FV* x 1) x 1 +
(DS4GM7090FV* x 1) x 1
Type -
PVE PVE PVE
Initial charge cc x n (1,100 x 1) x 2 (1,100 x 1) x 2
(1,100 x 1) x 1 + (1,400 x 1) x
1
-
Propeller Propeller Propeller
-
Top Top Top
EA
2 2 3
㎥/min
167 x 1 + 196 x 1 167 x 1 + 210 x 1 167 x 1 + 303 x 1
l/s 2,779 x 1 + 3,260 x 1 2,779 x 1 + 3,500 x 1 2,779 x 1 + 5,052 x 1
㎜Aq
11 11 11
Pa
110 110 110
-
BLDC Motor BLDC Motor BLDC Motor
W x n
(630 x 1) x 2 (630 x 1) x 2
(630 x 1) x 1 + (620 x 2) x 1
Type
Braze connection Braze connection Braze connection
Φ, ㎜ (inch)
15.88 (5/8) 15.88 (5/8) 19.05 (3/4)
Type
Braze connection Braze connection Braze connection
Φ, ㎜ (inch)
28.58 (1-1/8) 34.92 (1-3/8) 34.92 (1-3/8)
-
Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Type
Fin Treatment
Type
Output
Current Input
(Ducted)
Ducted
Type
Material
Pdesignh
Non_Ducted
Discharge direction
Quantity
Air Flow Rate
Model Name
Outdoor unit module 1
Outdoor unit module 2
Outdoor unit module 3
Outdoor unit module 4
Power Supply
Mode
Performance
HP
Capacity
Maximum number of connectable indoor units
Total capacity of the connected Indoor
Units
Current
Current Input
(Non-Ducted)
Current
Efficiency
Casing
Material
Heat
Exchanger
Compressor
Model Name
Oil
Fan
Type
External Static
Pressure
Max.
Fan Motor
Output
Piping
Connections
Liquid Pipe
Gas Pipe
Heat Insulation
Essential
2. Specification
