Samsung WF501ANW Trouble Shooting Guide - Cycle Count Check Mode

ALIGNMENT AND ADJUSTMENTS
8
Cycle Count Check Mode
Denition of Cycle Count Check Mode:
- CycleCountCheckModeistotallyupthenumberofwashings.
How to Enter:
- ToentertheCycleCountCheckMode,presstheSignalKeyduringServiceMode.
Cycle Count Check Mode:
1. ActivatetheServiceModeinadvance.
2.WhentheSignalkeyispressed,thetotalnumberofwashingswilllightupandasignalLEDwill
glow.
3.Themaximumnumberofcycleswillbe1999.
Thecounterwillrolloverto0andstartcountingagainafter1999.
4.Thecountingwillbecarriedoutattheendofthenormalcycle.
(FornormalandContinuousRuncycles,thecountiscarriedoutattheendofthecycles.
5. ToexittheCycleCountCheckMode,pressthe“Signal”keyagain.
S/W Version Check Mode
Denition of S/W Version Check Mode:
- S/WVersionCheckModeistobringupS/WVersioninformation.
How to Enter:
- ToentertheS/WVersionCheckMode,presstheSoilLevelKeyduringServiceMode.
S/W Version Check Mode:
1. ActivatetheServiceModeinadvance.
2. PresstheSoilLevelKeytobringupitssoftwareVersion
EX)GenerateL349atVersion49(L3isMicomcode,49isit’ssoftwareversion)
3. ToexittheS/WVersionCheckMode,presstheSoilLevelS/Wonceagain.
Then,itreturnstotheServiceModewithmotorRPMilluminating.
Toavoidriskofelectricalshock,personalinjuryordeath;disconnectpowertowasher
beforeservicing,unlesstestingrequirespower.
WARNING
