5.2 How to install Mount
1) Cut the mounting panel as Section 5.1 PANEL CUTTING
2) Insert the unit from its back terminal board side
3) Attach the left and right brackets to the unit to fix the unit to the
mounting panel. (Use screwdriver)
Do not tighten the mounting screw excessively, or the unit
case or bracket may be damage
!
CAUTION
