■ Operation D-Register
D-Register Symbol Description
D0101 STATUS_MODE
D0104 OPMODE
D0105 PWRMODE
For PROG RUN's (or FIX RUN) through communication,
TEMI 300 must be STOP(PROG STOP/FIX STOP)
Ex) TEMI 300 should be PROG STOP(D0104 = 0001, D0101 = 0004)
for switching FIX RUN TO PROG RUN
State Value
PROG/FIX RUNRUN 1
HOLD ON/OFFHOLD 2
SEGMENT STEPSTEP 3
PROG/FIX STOPSTOP 4
PROG MODEPROG 0
FIX MODEFIX 1
STOP MODESTOP 0
COLD MODECOLD 1
HOT MODEHOT 2
HOLD OFFHOLD 5
