Samwon Tech TEMI 300 - Page 69

■ Setting PROGRAM PATTERN setting D-Register
D-Register Symbol Description
PROGRAM GROUP is consisted D-Register for setting Program Pattern
4.8 PROGRAM
D1000 PT_SS1 PATTERN 1 START SEGMENT NO.
D1001 PT_ES1 PATTERN 1 END SEGMENT NO.
D1002 PT_RPT1 PATTERN 1 REPEAT NO. OF TIME
D1003 PT_JP1 PATTERN NO AFTER RUNNING PATTERN 1
.
.
.
.
.
.
.
.
.
D1090 PT_SS10 PATTERN 10 START SEGMENT NO.
D1091 PT_ES10 PATTERN 10 END SEGMENT NO.
D1092 PT_RPT10 PATTERN 10 REPEAT NO. OF TIME
D1093 PT_JP10 PATTERN NO AFTER RUNNING PATTERN 10
D1100 SEG_TSP1 PATTERN 1 TEMP SP
. . . . . . . . .
D1199 SEG_TSP100 PATTERN 100 TEMP SP
D1200 SEG_HSP1 PATTERN 1 HUMI SP
. . . . . . . . .
D1299 SEG_HSP100 PATTERN 100 HUMI SP
D1300 SEG_TM1 SEGMENT 1 TIME
. . . . . . . . .
D1399 SEG_TM100 SEGMENT 100 TIME
D1400 SEG_TS11 SEGMENT 1 TIME SIGNAL 1
. . . . . . . . .
D1499 SEG_TS1100 SEGMENT 100 TIME SIGNAL 1
D1500 SEG_TS21 SEGMENT 1 TIME SIGNAL 2
. . . . . . . . .
D1599 SEG_TS2100 SEGMENT 100 TIME SIGNAL 2
D1600 SEG_TS31 SEGMENT 1 TIME SIGNAL 3
. . . . . . . . .
D1699 SEG_TS3100 SEGMENT 100 TIME SIGNAL 3
