Samwon Tech TEMI1500 User Manual

[Fig. 3-16] Program operation operation screen 1
22
(2) Program operation #1 operation screen
●Thepatternnumbercannotbesetduringoperation.
●ItisascreenforMeasureddataandSetdata.
References
▶Itdisplaysthedirectionofcurrentpatternprocessing.
▶,: Settingdata>Measuringdataisdisplayedintemperatureincrease.
▶,: Settingdata=Measuringdataisdisplayedintemperaturemaintaining.
▶,: Settingdata<Measuringdataisdisplayedintemperaturedecrease.
1
2
5
3
6 7
8
9
10
11
12
13
4
⑬
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑫
⑪
Itdisplaysthetemperaturesettingdata(SP)tobecontrolled.
Itdisplaysthepresenttemperaturevalue(PV).
Itdisplaysthepresenthumidityvalue(PV).
Itdisplaysthehumiditysettingdata(SP)tobecontrolled.
Itdisplaysthecurrentdate/timeandLCDbacklightisoffwhenitistouched.
●
RedLEDlampattherighttopisONwhenthebacklightisOFFinstillstate.
Movingto[Fig.2-1Mainscreen]
●
Itdisplaysthekeypadtoinputthepasswordwhenmainbuttonrestrictionisset.
●
Referto[Fig.4-2Screeninrestrictionsettingofmainbutton]
Movingfromcurrentscreentonextscreen
Maintaining(HoldOn)orRelease(HoldOff)thecurrentlyoperating
temperatureandhumiditysetvalue.
Terminatingthecurrentlyprocessingsegmentandforcedmovingtothenextsegment.
Executionorreleasingtheautotuningwithtemperaturesetvalue(SP).
●
 Y/Nofthetuningbuttondisplayissetin[8.PIDgroup]in[Operationmanual]
Executionorreleasingtheautotuningwithhumiditysetvalue(SP).
●
 Y/Nofthetuningbuttondisplayissetin[8.PIDgroup]in[Operationmanual]
ProgramOperation/stopbutton
Clicktothisplace,PVdisplayexpandinoperationscreen.
●
Referto[Fig.3-19Programoperation#1expandedscreen]
