Samwon Tech TEMI1500 - Presented Value (PV) Graph View

44
6-2. Presented value (PV) graph view
●Itisascreentodisplaythedatarecordedin[3-1(5)Stationaryoperation3operationscreen]and[3-2(5)Programoperation3operationscreen].
●Thefunctionof,isnotoperatedincaseof1pageforrecordeddata.
●Thesearchingscrollbarisnotdisplayedincaseofsmallerrecordeddata.
●Thedateandtimesavedintothememoryaredisplayedoutthescreen.[Reference1]
[Fig. 6-5] Graph&Save setting screen 2 (Graph display is selected)
32
4
9
65
1
7 8
Purpleatbaselinetemperature(SetData,IndicatedData)andhumidity
(SetData,IndicatedData)isdisplayed.
●
Whenthecheckedistouched,itisdisappearedonthegraph
screenandwhenistouched,itisdisplayedonthegraphscreen.
●
Referto[Fig.6-5andFig.6-6Graph&Savesettingscreen2]
Displaytoupdatethegraphscreenimmediatelywhichisbeingsaved.
Movingfromcurrentscreentonextscreen
Baselinetodisplythedatacheckpoint
●
UsingthetouchscreenandNo.8Buttontomovetothepointwhere
wewant.
Thetimeaxisisexpandedorreduced.
MovingtothebeginningandendofthedisplayedPVgraphpage
Movingofgraphscreenbyonepage.
Movingthepurplelineonthegraphscreenup/downby1DOT
●
Whenthescreenistouched,theindicatedvaluesare
displayedwhilethepurplelinemoves.
Whenthebluepartonthebottomofthescreenistouched,itmoves
tothecorrespondingpageonthetouchedpointofXcoordinate.
①
②
③
⑥
⑤
④
[Reference1]
⑦
⑧
⑨
References
▶:Icontodisplayofnocardinsertionornorecognition
▶:IcontodisplaytheSDcardcapacity(usageislessthan75%)
▶:IcontodisplaytheSDcardcapacity(usageis75~90%)
▶:IcontodisplaytheSDcardcapacity(usageismorethan90%)
