[Fig.7-8]Timesignalsetting#2
[Fig. 7-9] Time signal setting #3
Parameter Initial value Setting range Unit
Delaytime
Operationtime
000.00.00(OFF)~999.59.59(Hour,Min,Sec)
000.00.00(OFF)~999.59.59(Hour,Min,Sec)
ABS
ABS
000.00.00
000.00.00
(2) Time signal time setting operation
●Thetimesignal2~17(TS2~17)operatedependingondelaytimeandoperationtime.
Thetimesignalis“ON”aftersettingtimeiselapsedindelaytimefrom
thecorrespondingsegmentstartingpoint.
●
However,thetimesignalisnotoperatedwhenthecorresponding
segmenttimeisbiggerthandelaytime.
Thetimesignalis“ON”bythedelaytimeincorrespondingsegment
is“ON”onlyforsettimeinoperationtime..
●
 However,thetimesignalis“ON”forthecorrespondingsegmentoperation
whenthe(delaytime+operationtime)isbiggerthancorresponding
segmenttimeanditisnotoperatedinthenextsegment.
①
②
