4.2 DISPLAY DESCRIPTION
4.2.1 LCD Screen Description
① ② ③ ④
DISTRESS TAG ITU
12:15PM 25W BSY
35.05N SIM ALL
126.02E ☎
16
A
1) * DISTRESS : Indicating channel used for international distress purpose.
* 12:15PM : Current time
* 35.05N : Indicating latitude of position where is own vessel (GPS antenna position as
current position)
*129.02E : Indicating longitude of position where is own vessel (GPS antenna position
as current position)
2) * TAG : Indicating that Tag is set in current channel.
(ESC/F+TAG Key set up)
* 25W (01W): Indicating transmit power and while in reverse mode, it indicates
transmit
* SIM (DUP): Indicating if current channel is Duplex or Simplex
* :☎ DSC function is available and when DSC signal is detected it goes to
reverse.
*  : Set up Weather channel.
3) * 16 : Indicating that current channel is No.16 .
4) * ITU (USA,CAN, WEA) : Indicating current setting channel.
* BSY : Indicating that current channel detects sensitivity signal
* ALL (TRI, DUL) : Indicating current using Watch or Scan function.
* USA A : In USA channel, it appears when it is simplex.
* CAN A : In CANADA channel, it appears when it is simplex.
* CAN B : In CANADA Channel, it appears with only receiving channel.
