4.4.7 Request a call of friend’s position (LL REQUEST)
DSC CALL ITU LL REQUEST ITU
CALL LOG BSY 〉STL6000D BSY
DIST LOG ALL STR580 ALL
〉LL REQ
16
STR680
16
① Press CALL/MENU shortly to get into
DSC mode and then select LL REQ.
② Select FRIENDS of whose
position user wants to know and
then press ENT. The below
screen will follow.
STR580 ITU STR580 ITU
LL REQUEST LL REQUEST
ALL TAG
CALLING…
16
WAIT ACK
16
③ This shows a calling is being made. ④ This shows it is waiting for the
acknowledge of the other party.
R:LL REQ ITU STR580 ITU
STR580 SEND AGAIN
35’25.05N ALL > YES TAG
127’05.55E
16
CANCEL
16
⑤ This is the display when a calling has
been received. The name of the other
party and the position data are indicated.
⑥ If user wants a retransmission,
choose “YES”, If not, choose “CANCEL”.
