S&A CWFL-2000 - III. Product Outlines & Parts

TY-JS-211220-009
8
III. Product Outlines & Parts
Note: The above-mentioned product outlines and part names are only for one of the models. The
outlines and parts installation may be slightly different in different models.
Power Switch
Temperature Controller
(laser head circuit)
Temperature Controller
(laser circuit)
Water Pressure
Gauge
Air Inlet
(Filter Gauze)
Water Supply Inlet
Electrical
Connecting
Box
Water Outlet L
(laser circuit)
Air Outlet
Drain
Water Level Gauge
Alarm Output Port
Water Inlet L
(laser circuit)
Water Outlet H
(optics circuit)
Water Inlet H
(optics circuit)
