S&A CWUL-10 - Restoring and General Parameter Settings

CWUL-05/10/20 Series
7
2. Restore to default setting
Press “ ” buttons at the same time and hold still while turn on the
machine, until the controller display “rE”. Release the buttons the controller will
enter working status after 6 seconds. And then all parameter value settings
restored to default setting.
3. Temperature controller parameters list
Order
Code
Item
Range
T-506B Temperature
controller Factory
Setting
Note
1
F0
Temperature setting
-20~ 40
25.0
Cooled water temperature ,constant
temperature working available
2
F1
Temperature
difference values
-15~+5
-2.0
Intelligent temperature control mode
parameter, control temperature difference
between water and ambient. Constant
temperature mode not available
3
F2
Cooling hysteresis
0.1~3.0
0.1
This parameter control water temperature
precise, the value more small, the precious
more high but energy efficiency ratio will
worse.
4
F3
Control methods
0~1
0
“1”Intelligent temperature mode,
“0”Constant temperature mode. UV laser
recommend use constant temperature
mode.
5
F4
Ultrahigh water
temperature alarm
1~20
10.0
When water temperature up to F0+F4 the
chiller will alarm , the alarm code display
“E2”.
6
F5
Ultralow water
temperature alarm
1~20
15.0
When water temperature low to F0+F4 the
chiller will alarm , the alarm code display
“E3”.
7
F6
Ultrahigh ambient
temperature alarm
40~50
45.0
When temperature of inlet air of chiller
higher than F6, the chiller will alarm the
alarm code display “E1”.,
8
F7
Password
00~99
8
User menu password can change
9
F8
Maximum water
temperature setting
（F9+1）
~40
30.0
Intelligent temperature mode parameter,
constant temperature mode not available.
10
F9
Minimum water
temperature setting
1 ~（F8-1）
20.0
Intelligent temperature mode parameter,
constant temperature mode not available.
11
F10
Alarm of sensor
pulse frequency
0~99
8
Eliminate the alarm by setting to 0
4. General settings adjustment
Press SET key to enter into the user-defined status. Meanwhile, PARAM SET is
on, indicates controller in parameters setting status.
Constant temperature mode displays setting water temperature value (Default
setting value is 25℃).
Press buttons can change setting value. Press confirm button
“RST” to save and exit after modified the values, then new values is working.
(Means F0 modified to new values, the chiller is running under new values).
If there is no more action within 20 seconds, it will automatically exit modifying
status without saving parameters.
