S&A RMUP-300 - Page 11

RMUP-300 Series
11
<7> Specifications
Model
RMUP-300AH
Voltage
AC 1P 220V
Frequency
50 Hz
Current
0.5-2.7A
Nominal cooling
capacity
0.41KW
Refrigerant
R-134A
Precision
±0.1℃
Reducer
Capillary
Protection
Overcurrent protection for compressor, flow alarm, over
temperature alarm
Pump power
0.05 KW
Tank capacity
3 L
Inlet and outlet
Rp1/2”
Max. lift
12 M
Max. flow
13 L/min
N.W
19.3 Kgs
G.W
22 Kgs
Dimension
480 X 490×180 cm (L×W×H)
Package dimension
590 X 530×250 cm (L×W×H)
Note: The current and nominal cooling capacity could be different under different working
conditions and configurations. The above information is for reference only. Please subject to the
nameplate of the actual delivered product.The max. pump flow is obtained by testing the pump
individually on test criteria GB/T 3216-2005.
